ITC TR Series 800W to 3200W Using Power Tracking Amplifier Tech 2 Channel 1U Professional Power Amplifier

ITC TR Series 800W to 3200W Using Power Tracking Amplifier Tech 2 Channel 1U Professional Power Amplifier photo-1
ITC TR Series 800W to 3200W Using Power Tracking Amplifier Tech 2 Channel 1U Professional Power Amplifier photo-2
ITC TR Series 800W to 3200W Using Power Tracking Amplifier Tech 2 Channel 1U Professional Power Amplifier photo-3
US$ 500 - 3,000 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
ITC
Model Number:
TR-800A TR-1000A TR-1200A
Type:
Professional Amplifier
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Brand Name ITC
Model Number TR-800A TR-1000A TR-1200A
Type Professional Amplifier
Channels 2 (2.0)
Place of Origin Guangdong, China
Feature

1)  In 1U design, using technique of class TR real-time power tracking amplifier, high performance amplifier circuit design, hifi sound quality to restore the quality of audio sources perfectly;
2)  Support soft-start to avoid causing interference to other devices, when it’s turned on and absorbs large current;
3)  With intelligent clipping distortion and over-current pressure limit system;
4)  With 30/50Hz high pass filter;
5)  With auto temperature control fan cooling system;
6)  Multiple modes: stereo, bridged and parallelism;
7)  Complete and reliable safety precautions, working mode indicators and multiple detection system for over-heat, over-pressure, low-voltage, overflowing, short, etc.

Technical Parameters
Output Power
(20 to 20KHz/THD≤1%)
TR-800A
TR-1000A
TR-1200A
Stereo/Parallel 8Ωx2
800W x2
1000W x2
1200W x2
Stereo/Parallel 4Ωx2
1200W x2
1500W x2
1800W x2
Bridged 8Ω
2400W x2
3000W x2
3600W x2
Connector
XLR, TRS
Voltage Gain (@1KHz)
38dB
39dB
40dB
Input Sensitivity
0dBu(1V)
Input Impedance
10KΩ unbalanced, 20KΩ balanced
Frequency Response
(≤1W)
20 to 20KHz/±1dB
THD+N
≤0.05%
SNR (A Weighted)
≥90dB
≥90dB
≥95dB
Damping Factor
(@1KHz)
≥200 @8ohm
Separating Degree
(@1KHz)
≥70dB
Protection
Over-pressure, low-voltage, overflowing, short, DC protection
Indicators
Power, temp. Protection, overflowing protection, clipping distortion, short protection, etc
Cooling Method
Fan cooling
Power Supply
AC 220V to AC 240V 50/60Hz
Power Consumption
2800W
3300W
4000W
Dimension (LxWxH)
483x390x44mm
Weight
8Kg
8.2Kg
8.5Kg
