ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP

ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP thumbnail-1
ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP thumbnail-2
ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP thumbnail-3
ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP photo-1
ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP photo-2
ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP photo-3
US$ 1,500 - 2,500 MOQ: 10 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ITC
Model Number:
TS-P880D
Contact Supplier Request Quote Chat Now
Guangzhou ITC Electronic Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen and HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ITC
Model Number TS-P880D
Feature

ITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital Sound Processor DSP

1) Built-in 2 high speed 64bit DSP TI L138 3648MIPS/2746MFLOPS, 48KHz A/D converter and D/A converter, sampling rate is up to 96KHz;
2) 8 channels balanced Mic/Line input, using organic thrum; 8 channels balanced output, using using organic thrum;
3) Support low delay DANTE network transmission protocol; 16 output and 16 input that are expandable;
4) Built- in adaptive feedback eliminate module for Mic (AFC), digital matrix Auto-mix module, and auto audio mixer module;
5) Support functions of grouping control, 8 group scene preset, SNMP/SMTP remote management and channel copy/paste/combined control;
6) Adaptive PoE interface for external control panel;
7) GPIO programmable control interface, 8 channel logic input and 8 channel logic output;
8) RS-485 for camera control to realize auto tracking camera;
9) RS-232 is for external RS-232 devices, like video matrix or is for being controlled by the third-party RS-232 devices, such as AMX, Crestron, etc;
10) Operating software in English and Chinese that uses GUI, which could run on WindowsNT4.0/2000/XP/Windows7.

Technical Parameters
Model
TS-P880D
Function of Input Channel
preamp, signal generator, expander, compressor, 5 band parametric eq
Function of Output Channel
8 band parametric eq, delayer, frequency divider, HP & LP, limiter
Input Impedance
20KΩ balanced, 10KΩ balanced
Input Quantization
48KHz/24bit
A/D Dynamic Range
114dB
D/A Dynamic Range
114dB
Phantom Power
DC 48V
Frequency Response
20~20KHz (±0.5dB)
Dynamic Range
103dB THD<1% @ 1KHz
Input CMRR
105dBu@+20dBu, 60Hz
THD
≤0.0056% @1KHz, +4dBu
Channel Isolation
112dB
Background Noise
-80dBA
SNR
103.7dB
Max. Input Gain
54dB
Output Impedance
100 ohm
Max Output Level
20dBu
Output Quantization
40KHz/24bit
Power Supply
AC 110V/60Hz to AC 230V/50Hz
Working Temp.
0℃~40℃
Power Consumption
60W
Dimension (LxMxH)
484x260x44mm
N.W.
3Kg
