Help CenterITC TS-P880D DANTE Network Having 8x8 Audio Matrixs Digital DSP Audio Processor
Related Products
-
ITC TS-15A02 Series 1000W 4ohm 2 Way Hi Fi Active Array Line SpeakersUS$ 400 - 600MOQ: 10 Units -
ITC TS-618S 600W 8ohm Extra Low Distortion PA Subwoofer 18 InchUS$ 360 - 600MOQ: 10 Pieces
-
ITC Precise Series Practical Function Hifi Audio Stereo AmplifierUS$ 250 - 350MOQ: 20 Units
-
ITC TS-5S Conference Used Large Covering Area Line Array Speakers ProfessinonalUS$ 125 - 210MOQ: 10 Units
-
ITC TS-2060W Series 60Wx2 120Wx2 1U Digital Mixer Bluetooth Amplifier With USBUS$ 150 - 300MOQ: 10 Units
It supports network transmission protocol of DANTE, could build up 8*8 matrix-style audio transmission channel to realize remote network transmission and audio sharing; using latest technology of 3rd generation audio processor, to provide 8 input/output for Mic/Line; the processor is integrated with multiple module, such as preamp, signal generator, expander, suppressor, equalizer, audio mixer, frequency divider, limiter, delayer, high/low pass filter, etc. It’s built in high-speed DSP TI L138 3648MIPS/2746MFLOPS to manage the audio processing module, and users could operate the device via software installed on computer which uses simulated operation interface.
It support external remote control panel which supports network control protocol of TCP/IP and is powered by POE or external battery. The connection method of multiple control panels supports “Daisy Chain” and “Star”. For software operation interface, it uses graphical programming module and wizard style programming method. And users could custom any widget to enhance the flexibility.
It’s suitable for many professional occasions, such as conference room, stadium, auditorium, hall, court, exhibition, public transportation center, etc.
1) Built in 2 64bit DSP TI L138 3648MIPS/2746MFLOPS; using 48KHz converter of A/D and D/A whose sampling rate is up to 94KHz;
2) To offer 8*8 matrix-styles input/output of balanced Mic/Line; using bare interface;
3) Integrated with multiple technical modules, such as Auto Feedback Cancelling for Mic Signal, Auto Audio Mixing for Digital Matrix, Auto Gain Control, Auto Audio Mixer, etc;
4) Support multiple functions, such as grouping control, 8 group of scene preset, remote management, remote management via SNMP/SMTP, copy/past and joint control for channels;
5) Support low delay network transmission protocol of DANTE which could realize audio network expansion;
6) With self-adaptive PoE control interface for external control panel;
7) Using GPIO programmable control interface, 8 logic input and 8 logic output;
8) Using camera control interface RS-485 to realize auto tracking camera;
9) Using bidirectional serial interface to control other external equipment like video matrix or to be controlled by the third-party device like AMX and Crestron;
10) With operation software in Chinese/English; minimalist and graphical control interface; could run on Windows NT4.0/2000/XP/Win7.
