ITC AP Series 60W 120W 240W 2 Mic Input and 1 Line Input Mixer PA Amplifier 100 V

ITC AP Series 60W 120W 240W Pre Mixer PA Amplifier 100V

ITC AP Series 60W 120W 240W Pre Mixer PA Amplifier 100V

ITC AP Series 60W 120W 240W Pre Mixer PA Amplifier 100V

It’s mixing amplifier with preamp. The rated power is from 60W to 240W which meet the demand of medium scale PA system. It’s with 2 modes of power output in order to be connected with constant voltage speaker and constant impedance speaker. They’re constant voltage output at 100V or 70V and constant impedance output at 4 to 16 ohm with 8 level indicators. Complete protection circuit is for over-heat, overload, short, etc. What’s more, it’s with excellent fan which is high efficiency and quiet when operating.

ITC AP Series 60W 120W 240W Pre Mixer PA Amplifier 100V

1)  Rated Power: 60W, 120W, 240W

2)  With 2 Mic input (5mV 1 Kohm) and 1 AUX input (350mV 10 Kohm)

3)  1 balanced/unbalanced Mic 1 input (2.5/5mV 1/2 Kohm)

4)  1 TEL input (Sensitivity is 350mV 2 Kohm)

5)  With internal tone control (Bass: ±10dB at 100Hz; Treble: ±10dB at 10KHz)

6)  Priority from high to low: TEL>Mic 1>Mic 2 & AUX

7)  With complete protection circuit for short, overload, over-heat, etc.

8)  2 modes of power output: constant voltage output at 100V or 70V; constant impedance output at 4 to 16 ohm

ITC AP Series 60W 120W 240W Pre Mixer PA Amplifier 100V
