ITC T-B20 Series Internal MP3 Player Mixing Bluetooth Amplifier

Guangzhou ITC Electronic Technology Limited

US$ 70 - 100 MOQ: 20 Units

Key Specifications

Brand Name:

ITC

Model Number:

T-B20/T-B40/T-B60

Type:

Professional Amplifier

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou Shenzhen and HK

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ITC

Model Number T-B20/T-B40/T-B60

Type Professional Amplifier

Channels 1

Place of Origin Guangdong, China

ITC T-B20 Series Internal MP3 Player Mixing Bluetooth Amplifier

Appearance

Product Description

ITC T-B20 Series Internal MP3 Player Mixing Bluetooth Amplifier

It’s mini Bluetooth amplifier. Smart appearance, light, portable. It’s suitable for home theatre, café room, classroom, etc.

Feature

ITC T-B20 Series Internal MP3 Player Mixing Bluetooth Amplifier

Built in MP3 player module and support Bluetooth.
Optional rated power output including 20W, 40W and 60W.
Hifi sound quality; support constant impedance speaker output of 4 to 16 ohm and constant voltage speaker output at 100V.
Mic input is in type of standard 6.3 mic jack; Line input is adopts RCA.
1 Mic input with individual volume control.
2 Line intput with individual volume control.
With function of off-line memory.
Mic 1 input has the highest priority.
Complete indication for power and signal.
Circuit protection for short, overload and over heat.

Specification

ITC T-B20 Series Internal MP3 Player Mixing Bluetooth Amplifier

Model	T-B20	T-B40	T-B60
Rated output power	20W	40W	60W
Speaker output	4~16Ω/100V
Input SPL&Source Impedance	MIC Input:+5mV,unbalance 6.3 connector AUX Input:350mV,unbalance RCA connector
Tone	Bass:100Hz±10dB,Treble:10KHz±10dB
Frequency response	80~16KHz(-3dB)
S/N Ratio	≥75dB
THD	Rated power output, distortion rate≤1%
Priority	MIC1 has the highest priority
Protection	short, overload and over heat
Input Power	AC 220V/50Hz
Power Consumption	40W	80W	120W
Dimension	284×188×66.5mm
Weight	2.8Kg	3.5Kg	4.2Kg
