Specifications
1.G350 plastic pacifier laser engraving machine2.Hiwin / PMI guide rail
3.Laser work / Laser cut software
G350 plastic pacifier laser engraving machine
Features:
Applicable material:
Plastic, wood, jade, crystal, rubber, plexiglass, paper, MDF, bamboo, acrylic, foam, fabric, jade, marble and other non-metal materials.
Applicable industry:
Mainly used for the engraving and cutting of little artistic works, such as portraits,badges, breast cards and various crafts, gifts.
Technical Parameters
Model |
G350 |
Laser Power |
45W / 40 W (Optional) |
Laser Type |
Hermetic CO2 glass tube |
Power Supply |
AC220±10% 50HZ/AC110±10% 60HZ |
Working Area |
500*300 mm |
Max Moving Speed |
0-50000 mm/min |
Worktable |
Worktable:manual / motorized up / down |
Locating Precision |
<0.01 mm |
Min Shaping Character |
Character:2*2mm,letter:1*1mm |
Operating Temperature |
5°C-35°C |
Resolution Ratio |
<4500 dpi |
Control Configuration |
DSP |
Data Transfer Interface |
USB (offline) |
System Environment |
WINDOWS 2000/ XP/ Vista/ Win7 |
Cooling Way |
Water cooling |
|
Graphic Format Supported |
Files which coreldraw, Photoshop, AutoCAD can identify (BMP,GIF,JPEG,PCX,TGA, TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK, DEX,CSL,CMX,AI,WPG,WMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) |
Compatible Software |
CoreIDraw,AutoCAD |
Cutting Thickness |
0-10 mm (Depends on different materials) |
Color Separation |
Separation of cutting up to 256 colors |
Sloping Engraving |
Yes,slop can be designed discretionarily |
Cuts off the Water Supply the Protection |
Yes |
Machine Dimension |
1020*650*590 mm |
Package Dimension |
1140*770*740 mm |
Net Weight |
82 kg |
Gross Weight |
105 Kg |
|
Optional Parts |
Chiller / Cylinder rotary attachment / Irregular rotary attachment / Auto focus / Aluminium knife / Honey comb |
