Specifications
2 laser engraving machine2.80w, 400x600mm
reldraw autocad
4.capacity 300 sets/month
5.Perfect after-sales
co2 laser engraving machine
Features:
Information:
working size:50*70cm
laser power:60w/80w/100w/130w(optional)
software:laserwor(coreldraw or photoshop)
red dot
auto focus
motorized up and down table
honey comb table
imported parts we used:
PMI square guide rail from Taiwan
lens form USA
Belt from Germany
locating percision:0.01mm
max cutting speed:500mm/s
Technical Parameters
Laser power : |
60W(optional) |
Laser tube life Span |
3000 hours. |
Applicable Materials |
Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc. |
Working area: |
500*700 mm |
Max moving speed: |
1500mm/s |
Laser energy control: |
1-100 set by hand or software |
Worktable: |
Electric Up and down table. Up to 25 CM |
Locating precision: |
<0.01 mm |
Min shaping character: |
Character: 2*2mm,; letter: 1*1mm |
Operating temperature: |
5°C-35°C |
Resolution ratio: |
<4500 dpi |
Laser type: |
Hermetic CO2 glass tube |
Power supply: |
AC220±10%50 HZ/AC110±10%50 HZ |
Control configuration: |
DSP. |
Data transfer interface: |
USB (offline). |
USB Ports |
2 |
System environment: |
WINDOWS 2000/WINDOWS XP/MAC/Vista |
Cooling way: |
Water cooling and protection system |
Graphic format supported: |
The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG, DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX). |
USER MENU |
Full English. |
Package Inclusion |
Software,VIDEO USER MENU CD,Air pump gun,Power cables, USB cables, Water tank,Water Pipe,Smoke Vent-pipe,Air Blow Pipe ,exhaust fan,Tools bag |
Memory |
64 MB |
Display screen |
LCD(SIZE 70*40 mm) |
Protection System |
Yes |
Option parts |
high-grade cooling system/double-head/cylinder rotary Jig/ irregular rotary Jig/ honeycomb table/ knifes table |
Guarantee |
1 year ,damageable spare parts(like laser tube,mirrors) 3 months |
Dimensions |
1480*1000*1080mm |
Dimensions(package) |
1600*1140*1300 mm |
Net Weight |
260KGs |
Gross Weight |
306KGs |
Recommended Ship way |
sea |
Packing list :
Machine parts |
Tools bag |
||||
Name |
Amount |
Units |
Name |
Amount |
Units |
Water pump |
1 |
set |
Manual book |
1 |
pcs |
Air pump |
1 |
pcs |
Software CD |
1 |
pcs |
Power line |
1 |
pcs |
USB line |
1 |
pcs |
Smoke pipe |
1 |
pcs |
Silicone |
1 |
pcs |
Water pipe |
1 |
pcs |
Focus rular |
1 |
pcs |
Air pipe |
1 |
pcs |
Paper for adjusting laser light way |
1 |
pcs |
Inner hexagon spanner |
1 |
set |
Plugs and Socket |
1 |
pcs |
