* Constant current mode power supply
* Universal AC input / Full range
* Protections:Short circuit / Overload / Over voltage
* Fully isolated plastic case
* Small and compact size
* Cooling by free air convection
* Pass LPS
* 100% full load burn-in test
* Suitable for LED lighting and moving sign applications
* Low cost / High reliability
* 2 years warranty
Specifications:
MODEL |
APC-16-350 |
APC-16-700 |
||
OUTPUT |
DC VOLTAGE |
12~48V |
9~24V |
|
RATED POWER |
16.8W |
|||
RATED CURRENT |
350mA |
700mA |
||
RIPPLE & NOISE(max.) Note.2 |
300mVp-p |
250mVp-p |
||
VOLTAGE TOLERANCE Note.3 |
5% |
|||
LINE REGULATION |
1% |
|||
LOAD REGULATION |
3% |
|||
SETUP, RISE TIME |
3000ms, 180ms / 230VAC 3000ms, 150ms / 115VAC at full load |
|||
HOLD UP TIME (Typ.) |
20ms/230VAC,15ms/115VAC at full load |
|||
INPUT |
VOLTAGE RANGE |
90 ~ 264VAC 127 ~ 370VDC |
||
FREQUENCY RANGE |
47 ~ 63Hz |
|||
EFFICIENCY (Typ.) |
82% |
82% |
||
AC CURRENT (Typ.) |
0.3A/230VAC;0.5A/115VAC |
|||
INRUSH CURRENT(max.) |
Cold start 35A/115VAC,70A/230VAC |
|||
LEAKAGE CURRENT |
0.25mA / 240VAC |
|||
PROTECTION |
CURRENT LIMIT |
5% rated output current |
||
Protection type : Constant current limiting type |
||||
OVER VOLTAGE |
50.4~60V |
27.6~33.5V |
||
Protection type : Shut off o/p voltage, clamping by zener diode |
||||
|
ENVIRO NMENT |
WORKING TEMP. |
-30 ~ +70 (Refer to output load derating curve) |
||
WORKING HUMIDITY |
20 ~ 90% RH non-condensing |
|||
STORAGE TEMP., HUMIDITY |
-40 ~ +80 , 10 ~ 95% RH |
|||
TEMP. COEFFICIENT |
0.2%/ (0 ~ 50 ) |
|||
VIBRATION |
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes |
|||
|
SAFETY & EMC (Note 5) |
SAFETY STANDARDS |
Design refer to TUV EN60950-1, EN61347-2-13, UL8750 |
||
WITHSTAND VOLTAGE |
I/P-O/P:3KVAC |
|||
EMI CONDUCTION & RADIATION |
Compliance to EN55022 (CISPR22) Class B,EN55015,EN61547 |
|||
HARMONIC CURRENT |
Compliance to EN61000-3-2 Class A,EN61000-3-3 |
|||
ISOLATION RESISTANCE |
I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH |
|||
WITHSTAND VOLTAGE |
WITHSTAND VOLTAGE |
|||
EMS IMMUNITY |
Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, light industry level(surge 2KV), criteria A |
|||
EMS IMMUNITY |
Compliance to EN61000-4-2,3,4,6,8, light industry level, criteria A |
|||
OTHERS |
MTBF |
Khrs min. MIL-HDBK-217F (25 ) |
||
DIMENSION |
77*40*29(L*W*H) |
|||
PACKING |
0.1Kg; 120pcs/14Kg/1.06CUFT |
|||
