Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Extruder > Air Bubble Film Machine
Air Bubble Film Machine
US$ 20,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Full Automatic Air Bubble Film MachineUS$ 20,000 - 60,000MOQ: 1 Set -
1000mm Stretch/wrapping Film MachineUS$ 9,200 - 60,000MOQ: 1 Set
-
Stretch/cling Film Production Line/machineUS$ 68,000 - 80,000MOQ: 1 Set
-
Tl Single Stretch Film Making MachineUS$ 43,000 - 58,000MOQ: 1 Set
-
1000mm Two Layers Co-extrusion Stretch Film MachineUS$ 10,000 - 52,000MOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
PE
Screw Design
Double-screw
Automatic Grade
Full Automatic
Place of Origin
Shanghai, China
Brand Name
TL-1500 mm Two Layer Air Bubble Film Machine
Model Number
TL-80-65-1500mm
Voltage
380V
Power(W)
110KW
Dimension(L*W*H)
1200*4500*3500
Weight
6800KGS
Certification
ce
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Air Bubble Film MachineHigh Configuration ,
Automatic Loader
Full automatic
TL-1500 mm Two Layer Air Bubble Film Machine
This machine uses LDPE,LLDPE granule material to produce air bubbe film, which widely used as post parcel packing,precise instruments packing funiture packing etc.
This machine is composed of extruder, air bubble forming device, perforaion device, widing device,cabinet control system.
| Model | TL-1500mm | TL-2000mm | TL-2500mm | TL-3000 |
| Screw Diameter | Φ80mm | Φ90mm/80mm | Φ105mm/90mm | Φ110mm/90mm |
| Auxiliary Screw Dia | Φ 65mm | Φ 80mm | Φ 90mm | Φ 100mm |
| Finished film width | 1500mm | 2000mm | 2500mm | 3000mm |
| Capacity/output | 90kg/hor | 110kg/hour | 150kg/hour | 200kg/hour |
| Main Motor Power | 22kw | 30kw | 37kw | 45kw |
| Auxiliary Motor Power | 15kw | 22kw | 30kw | 37kw |
| Total Power | 120kw | 200kw | 240kw | 260kw |
| Screw L/D | 30:1 | 30:1 | 30:1 | 30:1 |
| Power | 380V,3Ph,50Hz | |||
Skype: dannycheng921
Contact :Danny Cheng
Mobile: 0086 131 6625 1576
Send Inquiry to This Supplier
Mr. DANNY CHENG
General manager
Shanghai Tailian Plastic Machinery Manufacturing Co., Ltd.
Shanghai, China
Business Type
Manufacturer, Trading Company
Year Established
2009
Factory Size
3,000-5,000 square meters
Total Employees
101 - 200 People
