Help CenterFire Rated Cable Free Samples Armoured Power Cable NH-YJV22/NH-YJV23
Related Products
-
NH-VY Copper Conductor PVC Insulated Fire-resitant Cable PE Sheathed Fire-resistant Power Cable Single Core China ManufacturerUS$ 10 - 101MOQ: 10 Meters -
LOW SMOKE YJV Power CablesUS$ 10 - 101MOQ: 100 Meters
-
Aluminum Conductor PVC Sheathed Power Cable NH-YJLV 70mm2US$ 10 - 101MOQ: 10 Meters
-
Low and Medium VoltageYJLV Power CableUS$ 10 - 101MOQ: 100 Meters
-
Fire-resisant NH-YJLV23 0.6\1kv 3x95.3 CoreUS$ 10 - 101MOQ: 10 Meters
Operating characterristics
- Long-term allowable operating temperature of cable conductor ≤70
- Highest working temperature of cable in case of short circuit (the longest lasting time is not over 5s): ≤300mm2 cable conductor ≤160°C, ≥300 mm2 cable conductor≤ 140°C.
- The laying temperature should over 0℃,Permissible bending radius of cable:for single core armored cable, should be no less than 15 times of it’s outer diameter ; for multi-core armored cable, should be no less than 12 times of it’s outer diameter ;
- With fire-resistant property, N,ZAN,ZBN,ZCN,ZDN are 5 types
- The product is applicable for AC 50 Hz transmission and distribution lines with rated voltage of 0.6/1KV
standards
GB/T12706.1-2008
GB/T19666-2005
Technical parameters
packaging Details:
- In rolls or in wooden drum,
- In export wooden pallet,
- As per customer's requirements
Delivery Detail:
- 10 days after order
Why Choose Motian??
- Advanced connectors & assembly cables machines and testing equipments.
- Large production capacity, short delivery.
- Strict QC checking before delivery.
- OEM/ODM service available, help you on designing.
- Prompt quotation for your inquiry.
- More than 10 years experiences in cable and wire field.
- Professional connector and cable manufacturer, with good quality and competitive price.
- Samples are available for further evaluation and you are highly welcome to visit our factory at anytime!!
(1)We can produce
a.All type of flame retardant cable Flame
Retardant power cable is marked by “ZA”,“ZB”or “ZC”
Added before the above types.
b.We also can produce low-halogen low-smoke and LSOH flame retardant cable.
LHLS is marked by DDZA,DDZB or DDZC added before original type
Zero-halogen low-smoke is marked by WDZA,WDZB or WDZC added before original type
c.Waterproof, gopher protection, anti-termite, low toxicity cable.
d.Prefabricated branched cable.
(2) To armor the single-core cable,we adopt non-magnetic material or construction for reducing magnetic loss.Only D.C. Voltage is suitable for single-core armored cable(steel tape or steel wire armored cable)
Motian is a brand of Sichuan Motian Cable Co., Ltd, a Chinese leader in the energy and telecom cables and systems industry.
We mainly aim at managing XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated abc cable overhead cables, and stranded aluminum and ACSR. Annual product capacity of cables and wires is over 30,000 kilometers.
We obtained the certificate of ISO9001 and BV, and Cables must met the standards of China Compulsory Certification(CCC).
Motiancables and wires are widely used in the construction of buildings, airports, power transportation, urban and rural power network reformation and other main projects. Both of our products and factory are greatly commended by customers.
Now we seek for business cooperation all over the world. We sincerely welcome you to visit us.
• More than 10 Years Experience Focus On Cables & OEM manufacturing
• Authoritative certificates supported ISO:9001, BV, CCC
