XLPE ZR-YJV 8.7/15KV 3x240 Power cable
XLPE electric cable
1. Introduction
For XLPE insulated power cable, either chemical method or physical method is employed to transform the molecular structure of PE from chain into three-dimensional network, i.e. thermo-plastic PE is transformed into thermosetting XLPE. After cr·oss-linking, the thermal and mechanical properties of PE have been greatly improved while its excellent electrical property are still retained.
The maximum permissible operating of the conductor of a XLPE insulated power cable is 90°C.which is higher than that of paper, PVC or PE insulated power cable. The cable has the advantage of simplicity in construction, lightness in weight, convenience in application besides its excellent electrical, thermal, mechanical and anti-chemical corrosion properties. It can also be laid with no limitation of level difference along the route.
The mechanical and electrical properties of these cables are accordant with GB/T12706-2002 Power cables extruded insulation and their accessories of elated voltages 1kV(Um=1.2kV)up to 35kV(Um=40.5kV) and IEC60502-1997 Extruded insulation power cables and appendices for rated voltages 1kV up to 30kV.
2 The product is manufactured according to the standard of GB/T12706.1-2008 or 3C,CQC,NFTC request.
3 .The product is suitable for use in power transmission and distribution lines with rated power frequency voltage 0.6/1 kV~26/35 kV.
4. Instruction of application
4.1 Rated voltages: 0.6/1 kV~26/35 kV
4.2 The ambient temperature for installation: ≥0°C
4.3 Maximum conductor temperature in normal operation:≤90°C
4.4 Max operating temperature of con. When cable short-circuited (5s maximum duration): 250°C
4.5 Permissible bending radius:
Single cable: [20(D+d) ±5%] mm
Multi cable:[15(D+d) ±5%] mm
5,Type,designation and application
Type |
Designation |
Application |
|
Cu |
Al |
||
YJV |
YJLV |
XLPE insulated PVC sheathed power cable |
Suitable for indoor, channels, conduits. Unable to bear mechanical stress. |
YJY |
YJLY |
XLPE insulated PE sheathed power cable |
|
YJV22 |
YJLV22 |
XLPE insulated steel-tape armored PVC sheathed power cable |
Suitable for under ground, can bear mechanical stress, but can not endure large pulling force. |
YJV23 |
YJLV23 |
XLPE insulated steel-tape armored PE sheathed power cable |
|
YJV32 |
YJLV32 |
XLPE insulated fine steel-wire armored PVC sheathed power cable |
Can be installed in vertical well, and bear large mechanical pulling force. |
YJV42 |
YJLV42 |
XLPE insulated steel-wire armored PVC sheathed power cable |
|
YJV33 |
YJLV33 |
XLPE insulated fine steel-wire armored PE sheathed power cable |
|
YJV43 |
YJLV43 |
XLPE insulated steel-wire armored PE sheathed power cable |
|
Testing Machine
Packaging Details:Wooden drum, export standard package or as your request
Delivery Detail:Within 15days or mainly depending on your quantity
Why Choose Motian??
- Advanced connectors & assembly cables machines and testing equipments.
- Large production capacity, short delivery.
- Strict QC checking before delivery.
- OEM/ODM service available, help you on designing.
- Prompt quotation for your inquiry.
- More than 10 years experiences in cable and wire field.
- Professional connector and cable manufacturer, with good quality and competitive price.
- Samples are available for further evaluation and you are highly welcome to visit our factory at anytime!!
Motian is a brand of Sichuan Motian Cable Co., Ltd, a Chinese leader in the energy and telecom cables and systems industry.
We mainly aim at managing XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated abc cable overhead cables, and stranded aluminum and ACSR. Annual product capacity of cables and wires is over 30,000 kilometers.
We obtained the certificate of ISO9001 and BV, and Cables must met the standards of China Compulsory Certification(CCC).
Motiancables and wires are widely used in the construction of buildings, airports, power transportation, urban and rural power network reformation and other main projects. Both of our products and factory are greatly commended by customers.
Now we seek for business cooperation all over the world. We sincerely welcome you to visit us.
