Semi-Automatic 45 Degree Cutting Machines

Semi-Automatic 45 Degree Cutting Machines thumbnail-1
Semi-Automatic 45 Degree Cutting Machines thumbnail-2
Semi-Automatic 45 Degree Cutting Machines thumbnail-3
Semi-Automatic 45 Degree Cutting Machines thumbnail-4
Semi-Automatic 45 Degree Cutting Machines thumbnail-5
Semi-Automatic 45 Degree Cutting Machines thumbnail-6
Semi-Automatic 45 Degree Cutting Machines photo-1
Semi-Automatic 45 Degree Cutting Machines photo-2
Semi-Automatic 45 Degree Cutting Machines photo-3
Semi-Automatic 45 Degree Cutting Machines photo-4
Semi-Automatic 45 Degree Cutting Machines photo-5
Semi-Automatic 45 Degree Cutting Machines photo-6
US$ 3,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
FUJITECH
Contact Supplier Request Quote Chat Now
Shanghai Angzi Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Guangzhou China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name FUJITECH
Model Number FS4228A
Voltage 380V/50HZ
Dimension(L*W*H) 2100x1450x1450mm
Weight 1250kg
Certification ISO9001
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Semi-Automatic 45 Degree Cutting Machines

Semi-Automatic 45 Degree Cutting Machines

Product Description

FS4228A Band Saw Machine Performance:

1.Cutting capacity:

        0° Round :Φ280(mm)    Square :W×H=450×280(mm)

    +30° Round :Φ280(mm)    Square :W×H =370×280(mm)

    +45° Round :Φ250(mm)    Square :W×H =250×280(mm)

2.High reliability deceleration & variable speed control system.

3.Low-noise design.

4.Hard alloy clamping and guiding system.

5.Easy and accurate angle locating.

6.Smooth and precision roller design to reduce friction effectively in order to maintain smooth feeding.



Technical Parameters:



Model

FS4228A

FS4230A

FS4240A

Capacity

(MM)

Cutting angle

0°

+30°

+45°

0°

+45°

+60°

0°

+45°

+60°



Round

280

280

250

300

255

175

400

400

240



Square

450*280

370*280

250*280

450*300

255*300

175*300

600*400

400*400

240*400

Blade Speed

(M/MIN)

20,35,45,60,80

24,36,45,54,75

18,30,45,60,75

Blade Size (MM)

L3950*W27*T0.9

L4600*W34*T1.1

L5780*W41*W1.3

Blade Tension

 Handle Tension/Release

 Handle Tension/Release

 Handle Tension/Release





Motor

Blade Drive(KW)

2.2

3.0

4.0



Hyd.pump(KW)

0.75

0.75

0.75



Coolant Pump(KW)

0.04

0.04

0.09

Oil Scupper

Volume

Hyd Fluid(L)

30

30

40



Cooland Pump(L)

60

60

80

Weight/ KG

1250

1600

2150

Floor Space (MM)

L2100*W1450*H1450

L2300*W1500*H1570

L2950*W1700*H1740






Different cutting materials:

Used for cutting various metal materials(Steel pipe/bar, Iron, Copper, Aluminum,etc.)Semi-Automatic 45 Degree Cutting Machines

Cutting Tube:

Semi-Automatic 45 Degree Cutting Machines Semi-Automatic 45 Degree Cutting Machines



Semi-Automatic 45 Degree Cutting Machines



Semi-Automatic 45 Degree Cutting Machines



Semi-Automatic 45 Degree Cutting Machines



Band Sawing Machine Details:

Semi-Automatic 45 Degree Cutting Machines

Packaging & Shipping

         Experienced in selling band saw machine to more than 40 different countries,

we pack and load the machines well and prevent any damages during transportation.

Choice 1:  Nude packing &  Plastic protective cover.

Choice 2:  Wooden case.

Semi-Automatic 45 Degree Cutting Machines



Company Information

1. Located in Shanghai city, Building area 5000m².

2. 6 years band saw machine of production experience.

3. High efficiency,High precision and High stability,continuously satisfy customers' demands.

Semi-Automatic 45 Degree Cutting Machines



ANGZI Factory picture

Semi-Automatic 45 Degree Cutting Machines



Exhibitions:

Semi-Automatic 45 Degree Cutting Machines

Our Services

1.We test the Band saw machine to ensure the good quality.

2.We check the flatness degree to see if it is up to standard.

3.We also do some cutting experiments to check its using function.

4.Professional manufacturing assembly line.

5.Very strict quality control.

Semi-Automatic 45 Degree Cutting Machines

FAQ

Q1: What is the voltage and Hertz in your country?

A1:In China,the Voltage is 380V(3 Phase),the Hertz is 50HZ, we can change the voltage and

Hertz according to your requirment(also have 220V).

Q2.Can I have your quotation? & How to get suitable size band saw machine?

A2: First, please inform us which material you would like to cut and its details includes size,

Thickness,solid or hollow, round or square,ect. Without these parameters, we are not able to

recommend you the suitable machine.

Thank you for your attention to Shanghai ANGZI company,any question about band saw machine,Please contact us:
