bitumen/asphalt mixing equipment
- 10 Set / Sets per Month
- Qingdao port Shanghai port
- T/T
- 40-320TPH LB series bitumen plant for road construction
- LB3000 large asphalt batch mixing plant supplier
- China top 80t/h asphalt batch mixing plants
- 160TPH asphalt mixer,asphalt batch plant equipment
- Asphalt batch plant for road equipment,asphalt batch mix plant for sale
- 80tph asphalt batch plant for sale LB1000
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Sincola |
Model Number: | MHB20 | Voltage: | 380V(acoording to your local voltage) | Power(W): | 40kW |
Dimension(L*W*H): | 20.1*12.5*6.1m | Weight: | 23T | Certification: | CE ISO |
Warranty: | 12 months |
Packaging Details
Standards exporting package:mini asphalt mixing plant can be load in containers.
Product Description
bitumen/asphalt mixing equipment
Brief Introduction: MHB series asphalt mixing plant:
MHB Series mobile asphalt mixing plant is a bitumen mixture heating mixed machine. The mode of mixing is continuous and uniform, which has simple structure, moving and operating conveniently, good dedusting effect. The main application to built black roadway, goods yard and square for road, port and urban construction.
Main Paramters of 20TPH bitumen/asphalt mixing equipment :
1). Productivity: 20t/h
2). Mixture temperature: 130-160°C
3). Bitumen aggregate ratio: 3-9%
4). the maximum dust concentration: £200mg/Nm³
5). the height of black mixture unloading: 2400 mm
6). Fuel consumption: <140kg/h
7). installing power: 40kw
8). the overall unit weight: ≈23t
9). Overall dimensions: 20.1´12.5´6.1m
No | Components | Remarks |
1 | Cold aggregate Bins | 1 unit |
2 | Belt Conveyor | 1 unit |
3 | Drying & Mixing Drum | 1 unit |
4 | Fuel Burning System | 1 unit |
5 | Bitumen Pipelines | 1 unit |
6 | Hot Asphalt Elevator | 1 unit |
7 | Hot Asphalt Storage Bins | 1 unit |
8 | Dust-Filter System | 1 unit |
9 | Control system | 1 unit |
10 | Bitumen tank | 1 unit |
Other Models of MHB series- Mobile Asphalt Mixing Plant:
Models | MHB40 | MHB60 | MHB80 | MHB100 |
Output | 40t/h | 60t/h | 80t/h | 100t/h |
Assembly total power | 74 | 90 | 100 | 120 |
Temperature of finished materials | 120-160 | |||
Fuel | Coal(7-11kg/t) or diesel oil(5-7kg/t) |
Pictures for Main Parts of bitumen/asphalt mixing equipment :
Drying Drum
2. Cold Aggregate Batching Bins:
3. Bitumen Tank and Burning System
Guarantee Terms :
12 months for the Electrical Components ; 15 months for the Mechanical Components
After-Sale service:
Free technical guiding all the life for the machine.
During guarantee period , all the parts are free exchange .
After guarantee period ,all the parts are available .
Welcome you to visit our factory for more information on the MOBILE ASPHALT MIXING PLANT.
