Specifications
hammer mill1,ISO,CE
2,50-70T/H, 75KW
3,one crusher finishes the crush
4,professional for limestone
Professional New Designed Hammer Mill for Factory
Hammer crusher (hammer mill) is suitable for mid-hard and light erosive materials, whose pressure resistance strength is no more than 100Mpa and humidity lower than 15%, such as coal, salt, chalk, gypsum, blocks, limestone, etc. The PC-Hammer crusher is suitable for both dry and wet crushing of brittle, medium-hard materials for the mining,coal, metallurgic, construction material, road building, and chemical industries. the maximum, compressive resistance of the crushed materials can be up 150Mpa.
Working Principle of Hammer Crusher:
The motor drives the rotor rotate the hammer crusher with high speed through the belt, and on the rotor there are a series of hammers. When the materials get into the working area of hammers, they are crushed by the rotating hammers of the hammer crusher with high rotation speed, the products which are crushed to meet the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushed area by the hammers of the hammer crusher for being recrushed until they reached the required size. This machine can be adjusted according to user space grate section, change the particle size, to meet the different needs of different users.
Spare parts of hammer crusher
Use:The crusher can crush medium-hard and crispy materials,such as line stone and coal with compression resistance less than 150kg/cm2 in the fields of cement,mining,coal,electricity,chemical industry etc.
Technical Data of Hammer Crusher:
small types hammer mill
Types |
Rotor Diameters*length mm |
Mouth size W*L mm |
Feeding size mm |
Capacity t/h |
Motor power KW |
Theoretical weight t |
Dimensions L*W*H mm |
PC-0706 |
700*570 |
618*510 |
≤400 |
50-70 |
75 |
3.2 |
1950*1340*1480 |
PC-0808 |
800*750 |
780*610 |
≤500 |
80-100 |
132 |
5.3 |
2280*1790*1670 |
PC-0910 |
900*1000 |
1070*750 |
≤600 |
150-200 |
110*2 |
9.8 |
2600*2200*1940 |
PC-1012 |
1000*1180 |
1255*810 |
≤650 |
250-300 |
132*2 |
13.2 |
2800*2310*2210 |
PC-1213 |
1200*1280 |
1350*900 |
≤750 |
300-350 |
160*2 |
17.1 |
2970*2580*2510 |
Notes: If the parameters change, we will not notice separately, please excuse us.
Heavy types hammer mill
Types |
Rotor Diameters*length mm |
Mouth size W*L mm |
Feeding size mm |
Capacity t/h |
Motor power KW |
Theoretical weight t |
Dimensions L*W*H mm |
PCZ1308 |
1310*790 |
850*800 |
≤600 |
100-160 |
132 |
11.2 |
2818*2100*2390 |
PCZ1510 |
1500*950 |
1000*900 |
≤700 |
160-210 |
132*2 |
17.1 |
3260*3702*2750 |
PCZ1512 |
1500*1160 |
1210*900 |
≤750 |
250-320 |
160*2 |
18.9 |
3260*2580*2750 |
PCZ1615 |
1650*1452 |
1500*1200 |
≤1000 |
360-420 |
200*2 |
28 |
3456*2915*3185 |
PCZ1620 |
1660*1900 |
2000*1300 |
≤1200 |
500-800 |
315*2 |
46 |
3500*3100*3200 |
Company Breif
We are a solid Quarry/Mining crusher & equipment manufacturer rather than an assembly factory in Shandong province, east China since 1970.
Dear Sir or Miss, before you send this inquiry, could you please help us with the following questions?
--What is the raw material to be crushed?
--What is the raw material feeding size?
--What is the dicharging size you want?
--What is the processing capacity per hour or day?
