Most Cost-Effective Bulldozer D4 Track Pad RC Model Bulldozer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
HBXG
Model Number:
T165-3
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Brand New 119KW/162HP Chinese Bulldozer Price With Bulldozer PartsNegotiableMOQ: 1 Set -
Chinese Hot Cheap Price Small Crawler/Track Bulldozer HBXG SD8B For SaleUS$ 150,000 - 220,000MOQ: 1 Set
-
Made in China rc Bulldozer D6 Bulldozer PartNegotiableMOQ: 1 Set
-
HBXG Small R C Excavator Remote Control ExcavatorNegotiableMOQ: 1 Set
-
Bulldozer Brands HBXG T165-3 Swamp Bulldozer Spare Part From FactoryNegotiableMOQ: 1 Set
Place of Origin
Hebei, China
Brand Name
HBXG
Model Number
T165-3
Condition
New
Moving Type
Crawler Bulldozer
Machine Weight
17200kg
Dimension(Long * Breadth * High)
5416X3297X3160mm
After-sales Service Provided
Engineers available to service machinery overseas
Most Cost-Effective Bulldozer D4 Track Pad
RC Model Bulldozer
Product Description
Our 17 ton Bulldozer (Model:T165-3) is Semi-rigid suspended, mechanical transfer, hydraulic controlled track-type bulldozer.
Oil booster control clutch, normally meshed helical gear drive, coupling sleeve shift and two lever operation, the transmission has five forward and four backward speeds. Single lever pilot hydraulic controls implement. Superior cabin is designed with streamline outlook and electric monitor. Been Popular among customers by its many merits such as productive efficiency, easy operated, low maintenance cost.
T165-3 will be the ideal choice for transportation, desert working, oil field, electric power, mine project, etc.
It can be equipped with three shanks ripper, U-blade (7.4 cubic meter capacity) and other optional components.
Main Parameters
| Specification | ||
| Blade | Straight and tilting | Angular Blade |
| Ground pressure (kpa) | 66.7 | 67 |
| Min. ground clearance (mm) | 352.5 | 352.5 |
| Dozing capacity (m3) | 5 | 4.9 |
| Max. digging depth (mm) | 420 | 377 |
| Operation weight (kg) | 17200 | 17300 |
| Track gauge (mm) | 1880 | 1880 |
| Gradient | 30°/25° | 30°/25° |
| Blade width (mm) | 3297 | 3762 |
| Overall dimensions (L×W×H)(mm) | 5416×3297×3160 | 5716×3762×3160 |
| Undercarriage System | |
| Type | Swing type of sprayed beam, suspended structure of equalizer bar. |
| Number of track rollers (each side) | 6 |
| Number of carrier rollers (each side) | 2 |
| Pitch (mm) | 203 |
| Width of shoe (mm) | 500 |
| Gear | |||||
| 1st | 2nd | 3rd | 4th | 5th | |
| Forward (Km/h) | 0-2.50 | 0-3.30 | 0-5.68 | 0-7.53 | 0-10.64 |
| Backward (Km/h) | 0-3.53 | 0-4.61 | 0-7.94 | 0-10.53 | |
| Engine | |
| Engine Name | Weichai WD10G178E25 |
| Rated revolutio (rpm) | 1850 |
| Flywheel power (KW) | 121 |
| Max. torque (N.m/rpm) | 830/1000-1200 |
| Rated fuel consumption (g/kw.h) | ≤215 |
| Implement Hydraulic System | |
| Max. system pressure (MPa) | 12 |
| System output (L/min) | 185 |
| Pump type | Two groups Gears pump |
| Driving System | |
| Main clutch | Normally opened, wet type, hydraulic booster control. |
| Transmission | Normally meshed helical gear drive, coupling sleeve shift and two lever operation, the transmission has five forward and four backward speeds. |
| Steering clutch | Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated. |
| Braking clutch | Brake is oil two direction floating band brake operated by mechanical foot pedal. |
| Final drive | The final drive are double reduction with spur gear and segment sprocket, which are sealed by duo-cone seal. |
Finished Products
Warranty
The warranty period is one year.
Please be assured that we will provide excellent service under the warranty period:
Send the new spare parts by air express once our customers request an urgent replace of broken parts under warranty;
Send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance;
Arrange engineers to service machinery overseas in case our customers are in need help for installation and training.
Factory Pictures
Packaging & Shipping
Our packing and shipping are professional and dependable!
