Shenzhen GCOM GPON ONT S2000 Series GPON OLT ONU
GPON OLT ONU Specifications:
1. 3000 units Sells per Month
2. 1 pcs MOQ
3. 15 days delivery after received money
4. 1 year warranty
GPON OLT ONU Specification:
1* GPON standard port
4* Ethernet port (10/100/1000Base-T)
2* POTS port
Support WIFI
Plastic shell, 188*135*35 (W*D*H, mm)
Full-loaded power consumption is lower than 8 W
DC power switch, external power adapter, 12V/1.5A
GPON OLT ONU Product Overview:
GN2000 Series GPON OLT ONU is a new terminal level GPON ONT, which is a variety of FTTB FTTH FTTO accessing ONT published by GCOM for carrier-grade FTTH network applications. It can support pure data, Data +Voice, Data+ Voice+ WIFI and many other service accessing type. GN2000 Series GPON OLT ONU supports standard OMCI, can provide up to 1.25Gbps uplink and 2.5Gbps downlink high-speed transfer rate. It can fully meet carrier-grade FTTBFTTHFTTO equipment needs, working with our NGBN unified network management system.
GPON OLT ONU Business Features:
Attributes |
GN2000-04GS-2VW GPON OLT ONU |
GPON Feature |
ITU-T G.984xGPON standard GEM Encapsulation Mode DBA(Dynamic Bandwidth Assignment) 32*T-CONT 256*GEM Port Class B+ Optical Power VLAN to GEM Port mapping FEC(Forward Error Correction) Embedded OAM(Operations,Administration and Maintenance) PLOAM(Physical Layer OAM) OMCI 128bit AES(Advanced Encryption Standard) downlink encryption and uplink authentication Power-off alarm |
Protocol |
IEEE 802.3, IEEE 802.3u IEEE 802.3x IEEE802.3ah IEEE 802.3ad |
VLAN |
Port-based VLAN IEEE 802.1Q VLAN VLAN transparent transmit VLAN filtration Full VID and PVID Port+VLAN-based tag |
Address management |
1K 1K 512 512 MAC 256 multicast address Static MAC MAC address limit MAC address aging based on 1s Static IP address,DNS,DHCP |
IGMP |
IGMP V1,V2,V3 IGMP Snooping and Filter LAST Member Query(Snooping mode) Fast Leave Multicast service management |
Broadcast-storm suppression |
Broadcast suppression |
STP |
IEEE 802.1D / 1S / 1W Remote-loop detect |
Bandwidth control |
64K~100M bandwidth control |
QoS |
port / 802.1P / IP-TOS-based priority 4-level priority control DiffServ-based QoS priority classification QoS remark |
Updating |
Local TFTP Standard OMCI |
Management |
CLI Telnet |
Security |
Port lock Watch Dog Alarm and capacity statistics |
Maintenance |
Debug information output PING System log |
VOIP |
SIP,H248 Registration and authentication:call authentication, primary and secondary server Gain control,IP dialing,long number,secondary dial Voice codec negotiation,G711U,G711A,G729,G723,G726 Call process tone,echo cancellation,Packet loss detection and compensation,Compression and silence detection and comfort noise,packing time Supplementary services:Call Forwarding , Do Not Disturb feature , anonymous call blocking , call waiting, three-way conference , call back, call transfer , hotline , emergency call , call display restrictions , exhaled limit , alarm clock service , abbreviated dialing Fax:T38,G711,Modem |
