BBZ MH-SA portable ultrasonic level meter


Product Application

1. Water and wastewater treatment
Pumping stations, wet wells, biochemical reaction tanks, sedimentation tanks, etc.
2. Electricity, mining
Mortar pool, coal slurry pond, butter tank, stockyard or some mobile device control
3. Food Industry
Wineries, silos, tanks for containing food material, etc.
4. in conjunction with control system

Specifications

Sensors Level range
0 ~ 1OM
Dead band:
<0.3M
Minimum display resolution
1MM
Measuring accuracy
Range × 0.3%
Display
large-screen LCD
Operating frequency
20 ~ 2000KHz (optional)
Setting on site
complete through the unit button
Calibration
Factory calibration, field calibration
Output
RS485 (support Modbus)
SD card data collection
Operating voltage
1.5V AA battery *5
Power supply
DC9V, normal power: <1.5W
Physical properties
Host Dimension: 202 * 100 * 35mm
Keyboard: five SMD key
Material: Host: ABS plastic
Sensor: ABS
Sensor cable: 2M (any length optional)
Environmental performance
Working temperature: ≤80% RH non-condensing
Storage temperature: -40 ℃ ~ 70 ℃
Storage temperature: ≤80% RH non-condensing
Detection methods: 15Hz / s
Working pressure: normal pressure

Main Features

1. Rugged/stable sensor suitable for harsh industrial applications;
2. Built-in temperature sensor in the transducer, real-time automatic temperature compensation of the measured values;
3. The dead band can be set manually, shielding interference signal near the probe;
4.4 ~ 20mA isolated current output, optional fieldbus interfaces;

BBZ MH-SA portable ultrasonic level meter


Product description

1. Accurate measurement, reliable and generous appearance
2. Large scale integrated circuit and component placement rate up to 90% to ensure the long-term reliability and low power consumption
3. Large-screen display easy to use, support the SD card data acquisition and serial data download
4. Can record ten interference echo points
