Two-wire Ultrasonic Level Transmitter BBZ MH-CR

Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-1
Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-2
Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-3
Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-4
Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-5
Two-wire Ultrasonic Level Transmitter BBZ MH-CR thumbnail-6
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-1
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-2
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-3
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-4
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-5
Two-wire Ultrasonic Level Transmitter BBZ MH-CR photo-6
US$ 200 - 1,400 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
BBZ
Model Number:
BBZ MH-CR
Contact Supplier Request Quote Chat Now
Henan BBZ Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name BBZ
Model Number BBZ MH-CR
Product Description

Two-wire ultrasonic level transmitter BBZ MH-CR


Application


1. Water and wastewater treatment

Pumping stations, wet wells, biochemical reaction tanks, sedimentation tanks and other tanks

2. Power, mining

Mortar pool, coal slurry pond, water treatment

3. Oilfield

Specification

Measuring range
0 ~ 1M, 0 ~ 5M, 0 ~ 8M optional
Dead band
≤60 ~ 300MM (different ranges)
Accuracy
± 0.3% × range or ± 1MM
Output signal
4 ~ 20mA
Dimensions
Φ55 × 119 × G1 1/2 pipe thread (with gongs ring)
Working temperature
-10 ~ + 60 ℃
Power supply
DC12-24V/50mA
Installation
G1 1/2 pipe thread or Φ47MM hole
Line cable
1.5M (any length optional)
Protection class
Sensor IP68 (optional)
Explosion-proof class
Intrinsically safe: ExiaIIBT4 (optional item)

Features

1. Encapsulated transmitter suitable for harsh industrial applications
2. Built-in temperature sensor in transmitter for real-time automatic temperature compensation of measured values
3.4 ~ 20MA current output
4. Sturdy, stable sensor for harsh industrial applications
5. Strong anti-interference and online output adjustment
6. Can set the machine parameters inside through external resistor debugging

Description

Two-wire ultrasonic level transmitter BBZ MH-CR is able to meet most level measurement requirements not contacting with the industry media, completely solve winding, blockage, leakage, corrosion, maintenance inconvenience and other defects brought by pressure, capacitive, float and other traditional

measurement.


1. With the latest energy-saving components, enable current less than 3.5mA and work reliable within 9-32V DC supply voltage.
2. Designed for energy-saving, low cost, small installation space, supporting equipment and other application conditions.
3. Achieve a fully digital, user-friendly design concept, with perfect material/level monitoring and control functions.
4. Main chip use importing industrial grade microcontroller, digital temperature compensation and dozens of associated ASIC chip.
