BBZ MH-C Ultrasonic Level Meter With Small Dead Band

BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-1
BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-2
BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-3
BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-4
BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-5
BBZ MH-C Ultrasonic Level Meter With Small Dead Band thumbnail-6
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-1
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-2
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-3
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-4
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-5
BBZ MH-C Ultrasonic Level Meter With Small Dead Band photo-6
US$ 200 - 1,400 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
BBZ
Model Number:
BBZ MH-C
Contact Supplier Request Quote Chat Now
Henan BBZ Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name BBZ
Model Number BBZ MH-C
Product Description

BBZ MH-C Ultrasonic level meter with small dead band


Application

1. Water and wastewater treatment
Pumping stations, wet wells, biochemical reaction tanks, sedimentation tanks, etc.
2. Electricity, mining
Mortar pool, coal slurry pond, grease tank, stockyard or some the mobile device control
3. Food industry
Wineries, silos, food material storage tanks, etc.
4. Supporting with control system

Specification

Measuring range
0 ~ 1M
Dead band
<0.06m
Emission angle
9°
Accuracy
less than ± 1MM
Temperature compensation
Automatic temperature compensation
Operating frequency
40KHz ~ 430.0KHz (due to different model specifications)
Analog output signal
0 ~ 20mA; 4 ~ 20mA Load> 300Ω; 0 ~ 5V; 10 ~ 10V
Digital output
RS485 (support Modbus)
Switch output
NPN
Power supply
DC12-24V, Power consumption: <1.5W
Housing material
chrome plated copper
Dimensions
Φ30 × 106 × M30
Connection
threaded connection or spiro ring fixed
Installation
Thread M30 × 1.5
Outlet
standard socket of instrument or cable 1.5M (any length optional)
Protection class
IP65 (higher is optional)
Ambient temperature
-20℃~60℃
Ambient pressure
normal condition
Humidity
0 ~95%

Features

1. Housing made of chrome plated copper materials, quite compact and sturdy;
2. Main chip use industrial imported grade microcontroller, digital temperature compensation, and wide voltage input regulator and dozens of related ASIC, make it more stable and reliable
3. Strong anti-interference, set upper and lower limits node and online output adjustment by PC software
4. Can choose Analog and switching value, RS485 output, convenient interfaces with related facilities.
5. High reliability, no pollution, stable performance


Description

BBZ MH-C Ultrasonic level meter with small dead band is designed for monitoring and control small dead band, high precision and small installation space conditions with blind area less than 0.06m, accuracy up to ± 1mm.
