Specifications
1,submersible sewage pump2,made of hard alloy and reliable protection device
3,stainless steel impeller with cutter
submersible sewage pump with stirring cutting system
Specifications
submersible sewage pumps
1, Power cable: standard cord is 10m
2, Liquid Temperature: 40°c continuous
3, Motor: class B insulation, IP68 protection
4, Single Phase: Built-in thermal protector
5, Accessories: Float switch is available
Materials
Pump casing: Plastic
Impeller: stainless steel vortex
Double-sided Mechanical Seal: Burna-N elastomers
Motor side Mechanical Seal:carbon VS silicon carbide
Pump side mechanical seal: silicon carbide VS silicon carbide
Shaft:45# steel or stainless steel
Bearing:SKF/NTN/China
LIMITS OF USE
8Maximum operating depth 5m below waterlevel
8Maximum fluid temperature 40°C
8PH value in water :4-10
8 Maximum Passage for suspended solids: 35mm
8 Protection:IP68
General Characteristics
* Impeller with a grinder system
* Grinder system contain a revolving cutter and a plate withholes, sharpened edges that fine-chops filaments, preventing fouling of the impeller.
Model Analysis
Performance Table
Certificate
