Help CenterTop Selling- QT6-15B Used Concrete Block Making Machine
Related Products
-
QT6-15B Hydrafom Automatic Cement Hollow Block Machine for Sale PriceUS$ 36,499 - 76,499MOQ: 1 Set -
QT6-15B Automatic Concrete Paver & Brick Making MachineUS$ 36,499 - 76,499MOQ: 1 Set
-
QT6-15 Best Selling Products Block Manufacturing Machine PriceUS$ 38,399 - 58,399MOQ: 1 Set
-
Fly Ash /concrete /paving Brick/block Making Machine QT6-15US$ 38,399 - 58,399MOQ: 1 Set
-
QT6-15B Used Automatic Fly Ash Brick Making Machine for SaleUS$ 36,499 - 76,499MOQ: 1 Set
Specifications
1.Hydraulic cement brick making machine2.Moulding period: 15-20S
3. Produces hollow, solid, and curbing brick
4.Siemens
What’s the main features of QT6-15B used concrete block making machine
1.It is equipped with touch screen and Japan Mitsubishi PLC control system, making the whole process of mixing,
material loading, pressing run fluently and intelligently. It can produce 10 hollow bricks per mould and 54 standard brick per
mould.
2.High level steel, special welding technology and Siemens or Schneider motor make a perfect and stable machine performance
3. The way of four rods guiding and long guiding sleeve guarantees precise mould movement.
4.There are two types of stacker for client’s choice
5.It can not only produce concrete block but also fly ash, waste of coal and mine, etc. different mould can also produce hollow or solid bricks for different use.
How does it work?
Screw Conveyer (Optional fitment): loading bins of the instrument for transporting Fly Ash from the silos(optional fitting) or cement hopper (optional fitting) to the Batching Plant.
Batching Plant: It consists of three loading bins and one weighing bin. It also contains blet conveyers to convey materials from loading bins to weighing bin. Batching and weighing is done by PLC control. We can load three different types of material into the loading bin.
Conveyer Belt: When the Batching plant’s weighing bin trips according to the PLC control, the material comes to this conveyer belt. Then conveyer belt carried materials to the Mixture Machine.
Concrete Mixture Machine: All the ingredients are mixed in this mixture machine. Mixing time and speed is controlled by PLC. The inbuilt water pump adds water to the mixer automatically, as per requirement.
Block mold machine: This is key of the production line. It can press the mixed material. So it can make various hollow block, solid brick, paver brick and kerbstone.
Stacker: Stacker is used to lay the block automatically, which is high-efficient and labor saving.
What’ the main Parameters?
Host machine size |
3500*1700*2930mm |
power |
32.05KW |
Moulding area |
800x600mm |
Vibration force |
50-60KN |
Mould period |
15-25S |
Mixer model |
JS500 |
Pallet size |
940x830x25mm
|
Water consumption |
8T/day |
weight |
8T |
Project area |
300m2 |
Theoretical output of Hydraulic Block Making Machine QT6-15B
Size (LxWxH)(mm) |
piece/mould |
piece/hour |
piece/8 hrs |
400x100x200 |
12 |
2160-2520 |
17280-20160 |
400x150x200 |
8 |
1440-1920 |
11520-15360 |
400x200x200 |
6 |
1080-1260 |
8640-10080 |
400x250x200 |
4 |
720-840 |
5760-6720 |
230x110x70 |
30 |
5400-6300 |
43200-50400 |
Paver:200x100x60 |
24 |
4320 |
34560 |
Paver:200x163x60 |
9 |
1620 |
12960 |
Block samples
What advantages do we have?
(1) Fully automatic and hydraulic block making machine. Our products can produce all kinds of bricks by changing moulds, such as the solid bricks, hollow blocks, paver blocks and so on.
(2) German Siemens motors, Japan Mitsubishi PLC system, Omron travel switch are adopted.
(3) We adopt the heat-treatment and carburization technique to increase the lifespan of the moulds.
(4) Certificates: SGS/CE/ISO9001.
(5) Strong Steel Structure made of Q235B.
(6) There are three same size oil cylinders, which work at the same time to insure the same density and high quality of the blocks.
(7) 360° revolving method ensures the material to be more uniform.
(8) Cooling pump is installed to cool the oil so as to insure work of the hydraulic system.
(9) waste recycling tank is used to reduce the waste of materials.
-FOR PRODUCT
Company guaranty is 12monthes.
-FOR BUSINESS
Based on more than 7 years exporting experience, Sancidalo is always fast & effectively. We help our customers on matters other than orders
Clearing Customs, CO/CCPIT to save taxes, shipping arrangement and some other unpredictable knotty problems.
With 7 years experience on equipment exportation, Linyi Sancidalo Import & Export Co., Ltd. is able to offer you whole set of solution. But we are very young on Alibaba. As a baby, we focus more on quality, price and service. We treat you not only as business partner, but also as our friend.
