Plane/ Round heat transfer machine TH-30R

Product name

Plane/ Round heat transfer machine TH-30R

Model No

TH-30R

Certificate

CE, ISO-9001-2000

Brand Name

LC,China

Description

Hot Stamping Machines is German FESTO brand.Electrical components are imported from Japan.

While vaccum system is from Taiwan. It meets CE standard, with very stable running.

This hot stamping machine is fit for stamping on the surface of plane and round objects with small area.With fast speed and low energy consumption.

Advantage

1. Stamping temperature adjustable range from room temperature to 400C.
2. Stamping pressure is adjustable to install.
3. Automatic rear-and-front worktable ensures safe and quick operation.
4. Worktable capable of slight adjustment to rear-and-front, left-and-right and rotation.
5. The height of the stamping head adjustable accordingly.
6. Automatic foil feeding and rolling with adjustable function.

Parameter

1.  Name:Pneumatic Plane/ Round Hot Stamping Machines

2.  model:TH-30R

3.  product shape:Plane/ round

4.  Impression area: (Plane)90*100mm  (round) Φ30*90mm

5.  power:220V/50Hz
6.  Electrothermal Power::500W
7.  Air Pressure:0.5-0.7
8.  operation:Pneumatic

9.  system control:automatic

10  workbench:can be adjusted

11.  Stamping foil winding length - < 120 mm

12.  Stamping speed: 600 PCS/H

13.   Machine Outline Dimensions: 700*400*500mm

14    Machine Weight:81KG

Usage

Mainly applied to the field of craft,fabric handbag,leather,paper and plastic.

Shipping way

By sea, by air, by express

Delivery time

Within 7 days from the receipt of payment

Loading seaport

Shenzhen or Hong Kong, China

package

Plywood case

Price term

FOB Shenzhen, CFR, CIF, FCA, EXW etc

Payment term

100% T/T in advance(negotiation)
