TC-200R Heat Transfer Machine for Pritning on Glass Plastic Bottles

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Plate Type:

Other, hot stamping machine

Place of Origin:

Guangdong, China

Luen Cheong Printing Equipment Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China.

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other, hot stamping machine

Place of Origin Guangdong, China

Brand Name LC

Model Number TC-200R

Usage Paper Printer, Other, Paper Printer, Heat Transfer Machine for Bottles

Automatic Grade Semi-Automatic

Voltage AC220V

Gross Power 500W

Dimensions(L*W*H) 1260*600*1850MM

Weight 420kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Product name	TC-200R Heat Transfer Machine for pritning on Glass Plastic Bottles
Model No	TC-200R
Certificate	CE, ISO-9001-2000
Brand Name	LC,China
Description	Machine stability. 8mm thickness of the cast iron body and a shape. Durability, service life of up to 30 years
Advantage	1, the toggle mechanism design, strong pressure, air pressure consumption; 2, stamping pressure, temperature, transfer time is adjustable; 3, the table can be moved manually before and after, to facilitate the safe and quick operation; 4, the table can be around the rotation adjustment 5, automatic document feeder, the collection of paper, and can adjust; 6, stamping head lift height adjustable; 7 shuttle table driven the the workpiece smooth rotation Stamping stamping quality is stable. 8 for stamping curved or round face, remove the shuttle table is the plane tipping machine.
Parameter	The Max.Stamping pressure ≤ 1000kgs Max stamping diameter / full circle printing Φ140mm/Φ60mm Stamping head height adjustable stroke: 53mm Thermal transfer Cots area: outside diameter: 100 × length of 150mm. Red 45 degrees -85 degrees customers freedom of choice.
Application area	learth , toys , plastic parts, glass bottles
Free fittings	1 Set/Sets
Shipping way	By sea, by air, by express
Delivery time	Within 5 days from the receipt of payment
Loading seaport	Shenzhen or Hong Kong, China
package	Plywood case
Price term	FOB Shenzhen, CFR, CIF, FCA, EXW etc
Payment term	100% T/T in advance(negotiation
