SJO Rubber Insulated and Jacket Power Cables
1.Standard
the welding cable can be produced according to the standard 245 IEC 81,ICEA S-75-381
2.Specific Property for Using
(1).The cable can be used in the connectors of electric weld and pliers of the electrical welding whose toward earth voltage of the low voltage is not more than AC 200 V and the pulsant DC peak value is 400V.
(2).The long-time permissible working temperature of cable is not more than 65.
3.Name and IEC Standard
(1).Rubber Sheathed Welding Cable 245 IEC 81
(2).Rubber Sheathed Welding Cable 245 IEC 82,which is made of chloroperene or the composite stretchy materials.
4. Conductor Materials: Copper, Tinned Copper or CCA
5. Jacket: Rubber or PVC
6. Applications: For Welding Machines and so on
7.The general data of the cable 245 IEC 81 and 245 IEC 82
No minal Section |
Copper Wire |
Insulated Sheath |
Average of the Max |
Conductor Resistance |
Weight |
10 |
322/0.20 |
1.8 |
9.7 |
1.91 |
151.6 |
16 |
513/0.20 |
2.0 |
11.5 |
1.61 |
224.0 |
25 |
798/0.20 |
2.0 |
13.0 |
0.758 |
326.0 |
35 |
1121/0.20 |
2.0 |
14.5 |
0.536 |
430.0 |
50 |
1596/0.20 |
2.2 |
17.0 |
0.379 |
600.0 |
70 |
2214/0.20 |
2.4 |
19.5 |
0.268 |
818.1 |
95 |
2297/0.20 |
2.6 |
22.0 |
0.198 |
1082 |
