Help CenterAmphenol 957 2.16mm Pitch Champ IDC Type Side Cable Exit 100 Pin Connector Plug
Related Products
-
57 Series Centronics 64 Pin Right Angle Type Female Socket 32 Pairs Connector PCB MountingUS$ 1 - 2MOQ: 1000 Pieces -
14 Pin 24 Pin 36 Pin 50 Pin and 64 Pin Configurations Combo Connector Female Type PCB Mount Right AngleUS$ 1 - 2MOQ: 1000 Pieces
-
Centronics Male Plug Communication Connector PCB Mount Right AngleUS$ 1 - 2MOQ: 1000 Pieces
-
Female Centronics PCB Mount Right Angle 57 Series DDK 40 Type Receptacle Connector With Bail LockUS$ 1 - 2MOQ: 1000 Pieces
-
57 Series Centronics Female 90 Degree Angle Telecom Connector PCB Mounting With Spring LatchesUS$ 1 - 2MOQ: 1000 Pieces
Specifications
Model Number:FUY57057Zinc Alloy Dust Cover
1,ROHS compliant, UL-approved
2,Competitive price
3,Quick delivery
Specifications
Product features:
Model: FUY57057
Connector Classification: Plug
Product Type: Connector
Product Line:CENTRONIC/CHAMP
Connector Style: Male
Cover Type :Tapered Cover
Mechanical Attachment:
Com Material:Thermoplastic
Terminal Related Features:
Certerline :2.16mm(0.85 in)
Number of Position: 100 pin
Contact Plating: Gold (A:5u" ,B:10u"C:15u",D:30u")
Contact Material: PHOSPHOR Copper Alloy
Housing Features:
Connector : Plug
Shell: Zinc Alloy
Insulator Material:PBT&Glass-fibre Reinforced
UL Flammability Rating: UL-94-V0
Finish
Electrical Specifications:
Current Rating: 5Amp
Voltage rating: DC 1000v per minute
Insulator Resistance: 1000Mn MIN.(at 500V DC)
Operation Temperature: -55°C to +105°C
Packaging
Vacuum Tray
Application
VDSL Teleccom Equipment
Computer Peripherals
