Home > Products > 36 Pin Connector > DDK 36 Pin Champ Solder Cup Male Plug Pin Header Brass Contact Ribbon Connector Certificated UL
DDK 36 Pin Champ Solder Cup Male Plug Pin Header Brass Contact Ribbon Connector Certificated UL
US$ 0.8 - 1.5
/ Piece
1000 Pieces(Min. Order)
- Shenzhen / Guangzhou
- T/T Credit Card
You May Like
-
36 Way Male Plug Header Solder Cup Contact 2.16mm Easy Type Connector Certified UL
-
36P DDK Ribbon Plug Male Solder Wire Connector With Solder Cup Contact PBT Insulator
-
Solder Cup Contact 36 Pin Male Plug Header With Hard Connection DDK Ribbon Connector Certified UL
-
36 Way Solder Ribbon DDK Connector Male Plug 2.16mm Pitch MD Type Shell Black or Blue Insulator Header Certified UL
-
Centronic 36 Way Telecoms System Ribbon Connector DDK Solder Pin Male Plug Easy Type Header Certified UL
-
DDK Solder Type 2.16mm Pitch Brass Contact Male Header 36P Connector With Tope Cable Entry Matel Cover Certified ULE 346172
Product Details
| Place of Origin | Guangdong, China | Brand Name | FUYCONN | |
| Model Number | FUY57097-36P | Type | Other, Centronc Solder Connector | |
| Application | Other, Cable to Panel | Gender | Male |
Product Description
Specifications
Item No.: FUY57097-36P1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample
Specifications
Material & finish
| Product Modul | FUY57097 |
| CONNECTOR TYPE | Male of Classic type |
| NO. OF CONTACT | 14,24,36,50,64 pins |
| CONTACT TYPE | Plug |
| INSULATOR COLOR | Bule or Black |
| PLATING | Phosphor bronze and Gold plated |
| GOLD THINKNESS | 1U", 3U", 5U" ,10U", 15U" 30U" |
| SHELL | Steel,Nickel plated steel |
| INSULATOR | PBO&Glass-fibre reinforced(UL-94-V1) |
| COM MATERIAL | Thermoplastic |
| CURRENT RATING | 5Amp |
| DIELECTRIC STRENGTH | 1000V per minute |
| INSULATOR RESISTANCE | 1000MΩMin.(at 500v DC) |
| OPERATION TEMPERATURE | -55°C to +105°C |
| SPECIAL FUNCTION | Rear Rivet Insert 3.0mm |
Technical Parameters
Application
VDSL Teleccommunications Industry
Computer termial ,Test Equipment
Computer Peripherals,Telemetering etc.,
About FUYCONN
DongGuang FUYCONN ELECTRONICS CO.,LTD was found in 2004
In 2008, we experienced a historic of transition .
But we are always to persist provide the most cost-effective pricing, on time delivery, and stable quality's products, as well as we have a professional R&D and engineering team to enabling smarter, faster, better technologies to connect products to possibilities.
