Help Center0.6/1kv PVC Insulated Steel Tape Armored PVC Sheath Power Cable
Related Products
-
PVC Insulated Thin Round Steel Wire Armored PVC Sheath Power CableUS$ 0.48 - 99.8MOQ: 1000 Meters -
AL/CU Conductor Multi Core Core 25mm XLPE Insulated PVC Sheath Power Electric Cable PriceUS$ 0.48 - 99.8MOQ: 1 Kilometer
-
Steel Tape Armored Power Electric Cable Price Wire With Rated Voltage Aluminum Conductor XLPE Insulated PE SheathUS$ 0.48 - 99.8MOQ: 1 Kilometer
-
0.6/1kv Rated Voltage AL/CU Conductor Multicore Core 25mm XLPE Insulated PCV Sheath Steel Tape Armored Power Electrilc CableUS$ 0.48 - 99.8MOQ: 1 Kilometer
-
0.6/1kv PVC Insulated Thin Round Steel Wire Armored PE Sheath Power CableUS$ 0.48 - 99.8MOQ: 1000 Meters
XLPE insulated power cable not only has excellent electric, mechanic properties, but also has powerful resistance chemical corrosion, antiaging and long life. Voltage grade is up to 26/35kv, crosssection area is up to 630 sqmm ( copper or aluminum conductor). The core number of conductor is from 1 to 5. Conductor longtime operating temperature is 90 degrees. In short circuit, conductor highest temperature should be not more than 250 degrees.
Application:
It is generally applied to the fields including substation, construction, mines, metallurgy, petrochemical industry for transmission and distribution electric energy. For laying indoor, tunnel, cable trench and underground.
Model and Name
Model |
Description |
Application |
|
Cu |
Al |
|
|
YJV |
YJLV |
XLPE insulation PVC sheath power cable (Cu/XLPE/PVC) |
For laying indoor, tunnel, cable trench and underground, the cable couldn't bear mechanical force outside |
YJY |
YJLY |
XLPE insulation PE sheath power cable (Cu/XLPE/PE) |
|
YJV22 |
YJLV22 |
XLPE insulation, steel tape armor, PVC sheath power cable (Cu/XLPE/PVC/STA/PVC) |
For laying indoor, tunnel, cable trench and underground, but it couldn't bear great pulling force. |
YJV23 |
YJLV23 |
XLPE insulation, steel tape armor, PE sheath power cable (Cu/XLPE/PVC/STA/PE) |
|
YJV62 |
YJLV62 |
XLPE insulation, no magnetism steel tape armor, PE sheath power cable |
|
YJV32 |
YJLV32 |
XLPE insulation, thin steel-wire armor, PVC sheath power cable (Cu/XLPE/PVC/SWA/PVC) |
Be applicable to the well, water inside and fall in the bad soil. The cable is able to bear external mechanical forces, and certain force. . |
YJV72 |
YJLV72 |
XLPE insulation, have no the magnetism thick steel-wire armor, PVC sheath power cable |
|
YJV42 |
YJLV42 |
XLPE insulation, thick steel-wire armor, PVC sheath power cable |
Be applicable to the well, underwater with the bottom of sea. The cable is able to bear external mechanical forces, and certain force. |
Producing Process
Testing Equipment
Why you choose us ?
Contact Us
