Specifications
1 Upcast plant2 free oxygen copper bar billet
3 upward continuous method
4 high quality&high productivity
I, Plant Introduction
The SYLZP series copper rod continuous casting line adopts the upward method continuous
casting process, and is the special equipment to produce the rectangular casting oxygen free
flat copper bar in high quality and long length.
II, Main technical parameters
| No. |
Model |
Size (thickness*width) MM |
Copper bar billet Qty |
Annual capacity |
Operating power (KW) |
Installed capacity (KVA) |
furnace form |
| 1 | SYLZP-1500T | 6*150-20*300 | 2 | 1000-1500T | 80 | 150 | Combined type |
| 2 | SYLZP-2000T | 6*150-20*300 | 3 | 2000T | 120 | 150 | |
| 3 | SYLZP-2500T | 6*150-20*300 | 4 | 2500T | 140 | 220 | |
| 4 | SYLZP-3000T | 6*150-20*300 | 6 | 3000-4000T | 230 | 300 |
III,The main spare parts brands
NO. |
Spare part name |
Brand |
1 |
AC servo motor |
YASKAWA |
2 |
Servo driver |
YASKAWA |
3 |
Frequency converter |
YASKAWA |
4 |
High-precision reducer |
NAIF |
5 |
PLC controller |
Mitsubishi |
6 |
Human-computer interface |
WEINVIEW |
7 |
Control apparatus vigour pieces |
Chengtai(Chinese famous brand) |
8 |
Winding motor & reduction gears |
Chengtai(Chinese famous brand) |
IV, Machine unit image
dragger unit
Rewinding machine
