100w 200w 12v Vertical Axis Wind Turbine Generator Price

Name: 100w 200w 12v Vertical Axis Wind Turbine Generator Price
Brand: NaiEr
SKU: 113306129
Availability: InStock

US$ 200 - 260 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

NaiEr

Model Number:

NE-200

Jiangsu Naier Wind Power Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port or according to your specific demand

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name NaiEr

Model Number NE-200

Type Wind Power Generator

Product Description

Vertical Axis Wind Generator Features:

1.Safe in operation:

a. Due to the darrieus design and aluminium alloy blade are based on maglev generator,

when wind in different directions blows on the wheel,

NE series products are rotating very easily at 1 m/s (starting wind speed) .

Morever ,its blades will not be able to fall down, broken or thrown far away.

b. With sensitive two colors on wind turbine boxes, birds issues have rarely been a concern.

It can be easily seen by birds or bats.

2.Noise:

The way of blades turning is clockwise that meets the aerodynamic principles.

Therefore, the NE series make noise less than 40 db in operation. (HAWB 100db)

3.Capacity of wind resistance:

Due to the advantage of darrieus design, NE turbines suffered in stronger wind force is minimized.

Once in a higher wind speed more than 65 meters/per second,such as hurricane, turbines would need to be shutdown gradually for safety reasons.

Vertical Axis Wind Generator Data Sheet

Model	NE-100	NE-200		NE-300
Power	100W	200W		300W
Output voltage	12/24VAC	12/24VAC		12/24VAC
Rated wind speed	8-10m/s	8-10m/s		8-10m/s
Start-up wind speed	2.2m/s	2.2m/s		2.2m/s
Survival wind speed	50m/s	50m/s		50m/s
Range of working wind speed	2.2-25m/s		2.2-25m/s	2.2-25m/s
Rotor diameter	0.7m		0.7m	0.7m
Height of blade	1.4m		1.4m	1.4m
Material of blades and numbers	Aluminium alloy/2
Speed regulation method	Electromagnetic control
Stop method	Electromagnetic brake
Wind energy utilized coefficient	30%-40%
Range of working temperature	-45°C-80°C
Top weight	15Kg
Suggested battery	2pcs12v100ah
Tower type and height	Guy cable tower/6m
