200w Small 12/24v Vertical Wind Turbine Generator for Home Use

Name: 200w Small 12/24v Vertical Wind Turbine Generator for Home Use
Brand: naier
SKU: 113306187
Availability: InStock

US$ 150 - 500 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

naier

Model Number:

Q-100W

Jiangsu Naier Wind Power Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name naier

Model Number Q-100W

Type Wind Power Generator

200w small 12/24v vertical wind turbine generator features

1,VAWTs are better able to harvest turbulent air flow found around buildings and other structures

2,VAWTs are ideal for both rural and urban applications, including roof top installations. Depending

on the shape of the roof, the wind flow over the roof can be concentrated, leading to an increased

energy output

3,Simple to install and maintain

200w small 12/24v vertical wind turbine generator technical data

Rated power	200w
Maximum power	230w
Rated voltage	12/24v
Start-up wind speed	1.3m/s
Rated wind speed	11.5m/s
Survival wind speed	45m/s
Top net weight	11.5kg
Gross	20kg
Packaging size	64x43x32cm
Wheel diameter	0.8m
wheel height	0.6m
Number of blades	5
Blades material	reinforced glass fiber
Generator	three phase ac permanent magnet generator
Magnet	NdFeB
Generator case	aluminum alloy
Control system	electronic magnet
Speed regulation	auto windward
Working temperature	-40-80°C
