Features
1)High quality industrial components,which guarantee its stability and reliability
2) a sound protection system
3)Anti-water,anti-dust shell make it applicable in various outdoor environment
4)Voltage/current limit charging make sure storage batteries are always at the best state of charging.
5)MPPT charging effectively draw power from generator to charge storage batteries.
6)Using PWM to unload redundant power,which protect batteries and ensure safety of generator
7)utility power switch over is optional, wind solar power is prefered,when power not enough , it can switch to utility power.
8)shell of aluminium alloy, light, good heat dissipation.
Technical data
Model |
| MAX-AUTO12/24V-WI-06 |
Voltage |
| 12/24V |
Wind generator rate power |
| 600W |
Wind generator rated current |
| 25A |
Maxium current output |
| 30A |
Protection | Overcharge,overdischarge,reverse connection of batteries,overloading,lighting protection,current limit,automatic braking or manual braking of wind generator | |
display | LED | |
function | MPPT charging | |
Unloading way | PWM electrodeless and noiseless unloading | |
Working temperature | -20~+60°C/35~85%RH(no condensing) | |
Remarks: parameters can be adjusted based on your configuration requirements | ||
Tips
Please provide below information when purchasing 600W MPPT charger in order that a reasonable product is recommended to perfectly match your configuration:
1.Rated voltage of batteries
2.Rated output power of wind generator
Product pic
