Pure Sine Wave Inverter
- Shanghai
- T/T Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | NaiEr | |
| Model Number | NE20-48-S | Output Power | 1 - 200KW | |
| Output Type | Single | Size | 400*230*365 | |
| Weight | 20kg | Input Voltage | 48v DC | |
| Output Voltage | 110/120/220/230/240VAC | Type | DC/AC Inverters | |
| Output Frequency | 50/60 Hz±0.05Hz |
Product Description
PERFORMANCE FEATURES:
² Frequency toroidal transformer, which ensures that inverter has high efficiency and low no-load loss.
² Perfect protection and alarming function, thus the system has a high stability.
² LCD display function, visually display battery voltage and other parameters.
² Pure sine wave output, compared with square wave or modified wave, has higher efficiency and higher capability of driving load.
² Adopts SCM to control, which makes the circuit structure simple, and the control method and control strategy more flexible.
² European CE certification.
OPTIONAL FUNCTIONS:
² By-pass function: It will switch to the city grid automatically when the battery is under-voltage or something wrong with the inverter, which ensures the continuity and stability of system.
² Chinese and English version : Customers can choose language versions according to requirement of Chinese and English or pure English Version.
APPLICATION AREAS:
² Stand alone wind power station, photovoltaic power station and wind/solar hybrid power station.
² Stand alone domestic household wind/solar hybrid power system, wind power system .photovoltaic power system.
² GSM base stations, expressway and other no-residential regions.
² Coastal islands, remote mountainous, border posts for regions shortage of or without electricity.
² Government demonstration projects, landscape lighting project, street light project etc.
WARM PROMPTS:
Customers, who will order the off-grid pure sine wave inverter, need to provide the following information:
² Rated DC input voltage.
² Whether output is single phase or three single phase
² Rated output capacity: rated output voltage, rated output frequency of the inverter.
² The load characteristic: Resistive load or Inductive load.
² With or without by-pass function: Customers should provide rated voltage and frequency of AC input if they need it.
TECHNICAL PARAMETERS
Model | NE20-48-S | NE20-96-S | NE20-120-S | NE20-220-S |
Rated Output Capacity | 2kVA | |||
Rated Battery Voltage | 48VDC | 96VDC | 120VDC | 216VDC |
Over Voltage Shutoff | 68VDC | 136VDC | 170VDC | 306VDC |
Over Voltage Recovery | 66VDC | 132VDC | 165VDC | 297VDC |
Under Voltage Shutoff | 42VDC | 84VDC | 105VDC | 189VDC |
Under Voltage Recovery | 48VDC | 96VDC | 120VDC | 216VDC |
No Load Loss | 0.35A | 0.2A | 0.15A | 0.1A |
Output Wave Form | Pure Sine Wave | |||
Display Mode | LCD | |||
Display Parameters | Battery Voltage, Output Voltage, Status parameters | |||
Cooling Mode | Fan | |||
Rated Output Voltage | 110/120/220/230/240VAC | |||
Wave Distortion | ≤4% | |||
Output Frequency | 50/60 Hz±0.05Hz | |||
Dynamic Response | 5% | |||
Overload Capacity | 120% 1min,150% 10s | |||
Inverter Efficiency | Maximum90% | |||
Noise(1m) | ≤40dB | |||
Insulating Strength | 1500VAC,1min | |||
Protection Function | Battery over voltage protection, Battery under voltage protection, Battery reverse connection protection, Output overload protection, Output short circuit protection, Overheating protection. | |||
Working Ambient Temperature | -20~50°C | |||
Working Altitude | ≤4000m | |||
Working Ambient Humidity | 0~90%, no condensing | |||
In order to serve our customers better. Our company can adjust parameters configuration according to customer’s requirement. | ||||
