Specifications
Inverter EVI heat pump1.Super high efficient and energy saving
2.Can work Minus 25 degree
3.Heating capacity:12--30KW
New design Inverter EVI heat pump water heater
EVI DC inverter heat pump fertures:
1.Compressor
Super heating EVI DC inverter scroll compressor.
2.Wide heating ranger
The heating ranger is expanded to -25°C
3.High speed heating start up
The performance of heating start up is improved.
4.High heating capacity
Industry-first injection circuit is equipped,which enable to keep the equal capacity with the even when outside temperature is -15 °C.but, The traditional heat pump can only reach 60% of the rated heating capacity output.
5.water heat exchanger
Water exchanger equipped with high efficiency Plate heat exchanger.
6. Evaporator
Evaporator is larger 30% than usual size to keep its high efficiency.
7. refrigerant
R410a refrigerant.
8. Refrigerant throttle control
electronical expansion valve
9. Defrost control
The optimization of the defrost mode, reduce the defrosting time and number of times, improve the heating efficiency.
10. Auxiliary electric heating control
Electrical heating element built in indoor unit as back up for emergency.
11. Operation control
LCD touch- screen controller.
12.heat pump control
Standard/adjustable heat curve.
| EVI DC Inverter Air To Water Heat Pump | |||||
| INDOOR UNIT | MACHRW | 050W/S(BE01) | 060W/S(BE01) | 080W/S(BE01) | 100W/S(BE01) |
| OUTDOOR UNIT | MAFP | 050A | 060A | 080A | 100A |
| Rated Cooling Capacity | kW | 12.5 | 15.0 | 20.0 | 25.0 |
| BTU/h | 42700 | 51200 | 68300 | 85400 | |
| Rated Input Power(Cooling) | kW | 3.91 | 4.69 | 6.25 | 7.81 |
| Rated Input Current(Cooling) | A | 10.3 | 7.1 | 9.5 | 11.9 |
| Rated Heating Capacity(A7/W45) | kW | 15.0 | 18.0 | 24.0 | 30.0 |
| BTU/h | 51200 | 61500 | 81900 | 102400 | |
| COP(A7/W45) | 3.60 | 3.60 | 3.60 | 3.60 | |
| Rated Input Power(Heating)(A7/W45) | kW | 4.17 | 5.00 | 6.67 | 8.33 |
| Rated Input Current(Heating)(A7/W45) | A | 10.9 | 7.6 | 10.1 | 12.7 |
| Rated Heating Capacity(A-15/W45) | kW | 15.0 | 18.0 | 24.0 | 30.0 |
| BTU/h | 51200 | 61500 | 81900 | 102400 | |
| COP(A-15/W45) | 3.0 | 3.0 | 3.0 | 3.0 | |
| Power Supply | V/PH/Hz | 220/3/50 | 380/3/50 | 220/3/50 | 380/3/50 |
| Compressor | EVI DC Inverter | EVI DC Inverter | EVI DC Inverter | EVI DC Inverter | |
| Compressor Qty | 1 | 1 | 1 | 1 | |
| Noise | dB(A) | 50 | 50 | 52 | 52 |
| Water outlet/water inlet | inch | 1" | 1" | 1-1/4" | 1-1/4" |
| Water Flow Volume | m3/h | 3 | 3.5 | 5 | 6 |
| Refrigerant Gas Type | |||||
| Indoor unit Net Dimensions(L/M/H) | mm | 600/600/760 | 600/600/760 | 1230/730/800 | 1230/730/800 |
| Indoor unit Shipping Dimensions(L/M/H) | mm | 650/730/810 | 650/730/810 | 1280/760/920 | 1280/760/920 |
| Indoor unit Net Dimensions(L/M/H) | mm | 930/390/1270 | 930/390/1270 | 1105/470/1540 | 1105/470/1540 |
| Indoor unit Shipping Dimensions(L/M/H) | mm | 1080/480/1310 | 1080/480/1310 | 1155/520/1660 | 1155/520/1660 |
| Indoor unit Net Weight | kg | 95 | 115 | 150 | 170 |
| Indoor unit Shipping Weight | kg | 110 | 130 | 180 | 200 |
| Outdoor unit Net Weight | kg | 70 | 70 | 65 | 65 |
| Outdoor unit Shipping Weight | kg | 75 | 75 | 75 | 75 |
| Note:(1)Cooling:Outdoor air temp:35°C/24°C,Outlet water temp:7°C,Inlet water temp:12 °C; (2)Using in ambient temperature:-25°C~43°C. | |||||
