55w solar module
Electrical Specifications
Model RSM60P-36 RSM55P-36
Max. power PMAX(Wp) 60 55
Max. power voltage UMPP(V) 18.5 17.86
Max. power current IMPP(A) 3.25 3.08
Ope ncircuit voltage Voc(V) 22.21 21.61
Short circuit current Isc(A) 3.57 3.35
Power Tolerance (%) ±5
Max. system voltage 1000V
Max.series Fuse A 6
No.of Bypass Diodes 1
Mechanical Characteristics
Frame Aluminium anodized,color: silver, black
Dimensions 650×665×30mm
Weight 5.3 kg
Front Cover 3.2 mm ultra clear,low iron tempered glass, with high light transmittance.
3.2mmBackside Cover TPT
Cells per Module 36 pcs (4X9)
Cell Type 36 pcs (4×9) polycrystalline156*62.4mm
Temperature Coefficients
Norminal Operating Cell Temp.(NOCT) 47°C(±2%)
Temp. Coefficient Voltage (Voc) -0.32%/°C
Temp. Coefficient Current(Isc) +0.03%/°C
Temp. Coefficient Power(Pm) -0.42%/
Output(Optional) Warranty
Cable 30mm
Connector no connector
12 years warranty on 90% of nominal power output.
25 years warranty on 80% of nominal power output.
2years material and workmanship warranty.
