120W mono Solar panel
USD $0.3 - $0.5
/ Piece
1 Piece(Min.Order)
- 500000 Piece / Pieces per Month
- shanghai
- T/T L/C D/P D/A
You May Like
- 12V Portable Mini Air Pump
- DC 12V Portable Heavy Duty Plastic Shell Air Compressor with Light Quality Choice
- Electric Portable Heavy Duty Plastic Shell Air Compressor -30mm 2 Cylinder
- 12V Heavy Duty Plastic Shell Air Compressor with Light
- 12V Mini Heavy Duty Plastic Shell Air Compressor Price
- 12V Heavy Duty Car Air Compressor /Tire Inflators with light - 30mm Cylinder
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | RISUN | Model Number: | 120W |
Material: | Monocrystalline Silicon | Size: | 1020*808*35 | Number of Cells: | 48 |
Max. Power: | 120w |
Product Description
Mono 120W solar panel
Module | Type (48 Series) | |||||
Encapsulation | Glass/EVA/Cells/EVA/TPT | |||||
Parameters | RSM48-125M/110W | |||||
Max power | Pm(W) | 120 | ||||
Tolerance | +/-3% | |||||
Open circuit voltage | Voc(V) | 44.48 | ||||
Short circuit current | Isc(A) | 5.31 | ||||
Max. power voltage | Vmp(V) | 36.18 | ||||
Max. power current | Imp(A) | 4.7 | ||||
Dimensions | (L*W*H) | 1020x808x35mm | ||||
Net Weight | (kg) | 7.5 | ||||
Max. system voltage | (V) | 1000VDC | ||||
Operate Temp. Scope | -40/+85'C | |||||
Resistance | 227g steel ball fall down from 1m height and 120m/s wind | |||||
Warranty | Pm is no less 90% in 10 years and no less 80% in 25 years | |||||
STC | (Standard Test Condition: 1000W/m2, AM1.5, and 25'C) |
