Waterproof Led Driver LPV-100-12 12 Volt ac dc Constant Current Led Driver

MODEL

LPV-100-5

LPV-100-12

LPV-100-15

LPV-100-24

LPV-100-36

LPV-100-48

OUTPUT

DC VOLTAGE

5V

12V

15V

24V

36V

48V

CURRENT RANGE

0 ~ 12A

0 ~ 8.5A

0 ~ 6.7A

0 ~ 4.2A

0 ~ 2.8A

0 ~ 2.1A

RATED CURRENT

12A

8.5A

6.7A

4.2A

2.8A

2.1A

RATED POWER

60W

102W

100.5W

100.8W

100.8W

100.8W

RIPPLE & NOISE (max.)  Note.2

80mVp-p

120mVp-p

120mVp-p

150mVp-p

150mVp-p

150mVp-p

VOLTAGE TOLERANCE   Note.3

±8.0%

±5.0%

LINE REGULATION

±1.0%

LOAD REGULATION

±6.0%

±2.0%

SETUP, RISE TIME NOTE.6

2000ms, 25ms / 230VAC 2000ms, 25ms / 115VAC

HOLD UP TIME (Typ.)

50ms/230VAC    16ms/115VAC at full load

INPUT

VOLTAGE RANGE NOTE.4

90 ~ 264VAC   127 ~ 370VDC

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

80%

85%

87%

88%

88%

89%

AC CURRENT (Typ.)

2.2A/115VAC     1.2A/230VAC

INRUSH CURRENT (Typ.)

COLD START 30A/115VAC 60A/230VAC

LEAKAGE CURRENT

0.25mA / 240VAC

PROTECTION

OVER CURRENT NOTE.4

110 ~ 150% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed

OVER VOLTAGE

5.75 ~ 6.75V

13.8 ~ 16.2V

17.25 ~ 20.25V

27.6 ~ 32.4V

41.4 ~ 48.6V

55.2 ~ 64.8V

Protection type : Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.

-25 ~ +70°C (Refer to output load derating curve)

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +80°C, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/ (0 ~ 50°C )

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for  60min. each along X, Y, Z axes

SAFETY &EMC(Note 4)

SAFETY STANDARDS

IP67 approved, Design refer to TUV EN60950-1,

WITHSTAND VOLTAGE

I/P-O/P:3KVAC

ISOLATION RESISTANCE

I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH

EMC EMISSION

Compliance to EN55022 (CISPR22) Class B

EMC IMMUNITY

Compliance to EN61000-3-2,-3

OTHERS

MTBF

703Khrs min. MIL-HDBK-217F (25°C)

DIMENSION

190*51*35mm (L*W*H)

PACKING

0.63Kg,20pcs/13.6Kg/0.51CUFT
