P10 Outdoor 128*32dots Led Message Display

Specifications

New Electronics Inventions Scrolling Message Display Board

Specifications

a.Double-line display series is also designed for retail, commercial, industrial and office use. You can choose single color or double-color.

b.It can display text and simple graphic, more than 25 methods of displaying the message(cyclic, scroll up, scroll down, open to center, open from left and so on)

c.Control method: We offer several different methods of programming and each product can be configured to the appropriate controllerrequired. A simple hand held keypad is a popular choice for small displays, while software is an option if you wish to program via your computer-RS232 is the standard interface or for greater distances RS485. For remote locations, dial-up or Wi-Fi modems can also be used.

Screen technical data

Display supported: Chinese, English, number, symbol

Scan mode:Software and hardware

Refresh rate:160HZ

Uncontrolled dot<1/10000

Pitch:10mm

Module size:320*160mm

Module qty:4*2=8pcs

Module dot:32*16dots

Display area:1280*320mm

Dimension:1280*340*150mm

Resolution:4096pixels

Asynchronous control system: remote controler or USB wireless cotrol system

Environment data

Life span>100 thousand hours

Mean Time Between Failure:50000hours (MTBF)

Working Voltage:DC 9-36V

Working temperature:-25 - 70°C

Storage temperature:-40 - 80°C

Average power consumption<15W (in normal usage)
