Natural Rubber Sheathed Cable for Welder
Yiteng Cable - Your Best Business Partner in the Cable Field!
Yiteng Cable - Always At Your Service!
Product Description
Flexible Rubber Sheath Copper | Aluminum Electric Welding Cable
1. Service Cnditions for Flexible Rubber Sheath Copper | Aluminum Electric Welding Cable
1.1. The rubber welding cable can be used in the connectors of electric weld and pliers of the electrical welding
whose toward earth voltage of the low voltage is not more than AC 200V and the pulsating DC peak value is 400V.
1.2. The long term permissible working temperature of cable conductive core is not more than 65°C.
Nominal Cross-section 10mm2-185mm2
2. Type & Specification for Flexible Rubber Sheath Copper | Aluminum Electric Welding Cable
Welding Cable Type and Description | ||||||
Welding Cable Types |
Welding Cable Name
|
≤(℃) |
||||
YH |
Natural rubber sheath for welding machine cable
|
65℃ |
||||
YHF |
Horoprene rubber or other syntheitic rubber sheath welding machine cable |
65℃ |
||||
| Yiteng Cable Technology Produces Flexible Rubber Cable for Welding Machine. Welcome Your Inquiry! | ||||||
| Description | International type | Chinese type |
|
Welding cable with Rubber compound sheath |
H01N2-D ( Common flexible) H01N2-E ( Extra flexible) |
60245 IEC 81 YH |
|
Welding cable with Polychloroprene compound (PCP) or other equivalent synthetic elastomer sheath |
60245 IEC 82 YHF |
3. Applications for Flexible Rubber Sheath Copper | Aluminum Electric Welding Cable
This type of welding cable is suitable for welding machine as secondary earth wire with secondary side to-ground voltage not more than 200V AC and impulse voltage peak 400V DC, or for connecting electrode holders.
Continuous operating temperature ≤60℃.
4. Main Technical Parameter for Flexible Rubber Sheath Copper | Aluminum Electric Welding Cable
H01N2-D 60245 IEC 81 (YH) 60245 IEC 82(YHF)
|
Nom. Area mm2 |
Max. Dia. of wire mm |
Nom. Cover Thickness mm |
Average O.D. mm |
Maximum DC Resistance at 20℃ Ω/km |
||
| Min. | Max. | Tinned copper | Untinned copper | |||
| 10 | 0.21 | 2.0 | 7.7 | 9.7 | 1.95 | 1.91 |
| 16 | 2.0 | 8.8 | 11.0 | 1.24 | 1.21 | |
| 25 | 2.0 | 10.1 | 12.7 | 0.795 | 0.780 | |
| 35 | 2.0 | 11.4 | 14.2 | 0.565 | 0.554 | |
| 50 | 2.2 | 13.2 | 16.5 | 0.393 | 0.386 | |
| 70 | 2.4 | 15.3 | 19.2 | 0.277 | 0.272 | |
| 95 | 2.6 | 17.1 | 21.4 | 0.210 | 0.206 | |
| 120 | 0.51 | 2.8 | 19.2 | 24.0 | 0.164 | 0.161 |
| 150 | 3.0 | 21.1 | 26.4 | 0.132 | 0.129 | |
| 185 | 3.2 | 23.1 | 28.9 | 0.108 |
0.106 |
|
H01N2-E 60245 IEC 81(YH) 60245 IEC 82 (YHF)
|
Nom. Area mm2 |
Max. Dia. of wire mm |
Nom. Cover Thickness mm |
Average O.D. mm |
Maximum DC Resistance at 20℃ Ω/km |
||
| Min. | Max. | Tinned copper | Untinned copper | |||
| 10 | 0.21 | 1.2 | 6.2 | 7.8 | 1.95 | 1.91 |
| 16 | 1.2 | 7.3 | 9.1 | 1.24 | 1.21 | |
| 25 | 1.2 | 8.6 | 10.8 | 0.795 | 0.780 | |
| 35 | 1.2 | 9.8 | 12.3 | 0.565 | 0.554 | |
| 50 | 1.5 | 11.9 | 14.8 | 0.393 | 0.386 | |
| 70 | 1.5 | 13.6 | 17.0 | 0.277 | 0.272 | |
| 95 | 1.8 | 15.6 | 19.5 | 0.210 | 0.206 | |
| 120 | 0.51 | 1.8 | 17.2 | 21.6 | 0.164 | 0.161 |
| 150 | 1.8 | 18.8 | 23.5 | 0.132 | 0.129 | |
| 185 | 1.8 | 20.4 | 25.5 | 0.108 | 0.106 | |
Quality Assurance:
With Yiteng, all cables are produced by strict inspection and testing:
1). Raw Material: Copper, Aluminium, PVC, PE and XLPE granules and all other materials for producing cables are all inspected carefully automatically. Only the qualified will be applied into cable production, the disqualified will be rejected.
2). Production Procedure: Cables in Yiteng are produced by advanced cable production machines.
3). Testing: Cables in Yiteng will not be packed until they are tested totally qualified. Cable Testing Machines includes Online Core Shift Detection Device, Tension Tester, Aging Test Chamber, Experimental Apparatus of Combustion, Insulation Resistance Tester and etc…
4). Package and Shippment:
With Yiteng Cable,
1. Cables are packed in standard export drums or other ways per customer's requirement;
2. Cables are handled and shipped carefully to ensure perfect package unpon customer's receiving.
Service Commitment-Why Choose US?
Yiteng Cable Technology Hebei Co., Ltd. sincerely ensure every present and potential customers and friends that we will always:
1. Make A Response with 12 Hours to All Custoemers;
2. ISO9001, ISO14001, CCC Certificates for Factory and Cable Products;
3. Factory Direct Supply and OEM Service of Cable Products;
4. Yiteng Cable will not only serve goods before selling, but will be better and better during sales and after sales;
5. All Customers' Information will be kept confidential without permission;
6. Production standard depends on customer's technic requirement, otherwise according to IEC, NFC standard;
7. Before production, technical data will be clarified with customer in case of any error or misunderstanding;
8. Trading Terms: FOB Tianjin, Qingdao, Shanghai, or CIF, CFR and other ways are also available;
9. Yiteng Cable can also help customers to seek for and inspect goods and factories of other categories once our cable deal is stable.
Yiteng Cable Technology Hebei Co.,Ltd. is a specialized manufacturer of cables.
Welcome Your Visit! Hope to Get in Touch with You! | |
Cable Factory Name |
Yiteng Cable Technology Hebei Co., Ltd. |
Factory Established in |
Year 1994, 20 Years’ Experience of Producing kinds of Cables |
Factory Location |
Jiajiakou Town, Ningjin County, Hebei, China |
Export Office Location |
No. 228 Jianshe North Street, Shijiazhuang, Hebei, China |
|
Cable Products Type
|
Electrical Wires |
Customized Cables per Requirement | |
Bare Aluminum Conductor AAC AAAC ACAR ACSR | |
Overhead Aluminum Aerial Bundle Cable (ABC Cable) | |
Aluminum Alloy Cable with/ without Armor and Interlock | |
Shielded/ Screened Control Cable | |
Computer Shielded Cable | |
Flexible Rubber Cable | |
|
Mining Cable, Flexible Rubber Mining Cable, PVC and XLPE Insulated Power Mining Cable | |
High Temperature Cable, Silicone Rubber Insulated Cable, Teflon Insulated Cable | |
Fire Resistant/ Flame Retardant Power Cable | |
Low Voltage Power Cable and Medium Voltage Power Cable with or without Armour (Armour Type: Steel Tape or Steel Wire) | |
Questions and Answers!
Experts of Yiteng Cable will always wait to answer all your questions!
1. When was Yiteng Cable founded?
Our factory was first establlished in Year 1994 and then it changed names several times.
2. What kinds of cables does Yiteng Cable produce?
1). Overhead Line Cables: Bare Conductor: AAC, AAAC, ACAR, ACSR;
ABC Cable( Aerial Bundle Cable): Solid Core, Duplex, Triplex, Quadruplex Service Drop, etc;
2). Alluminum Alloy Cable;
3). Shield Cable;
4). Control Cable;
5). Power Cable;
6). Special Cable in accordance with Customer's specific requirement.
3. What certificates does Yiteng Cable has been approved?
Yiteng Cable has been approved successfully by CCC, ISO9001 and ISO14001, SGS, etc;
4. What's the Minimum Order Quantity?
It depends on the production line. For the Overhead Line Cable, the production line is long, so the MOQ should be long enough for the production line to run.
5. Can customers audit Yiteng Cable?
Sure, Yiteng Cable alwlays welcome customers, home and aborad, come and audit the factory before cooperation. Cables in Yiteng can also be inspected by customers personally or the third party every time before shippment.
Pls click and contact us for any question or problem! YITENG CABLE will always be at your service.
