Home > Products > Low Voltage Power Cable > Copper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cable
Copper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cable
- 1000000 Meter / Meters per Month
- Tianjin port or any port in China
- T/T L/C D/P D/A Credit Card PayPal
- Mooring rope cable
- Manufacturer of waterproof gas electric composite cable for air ducts, specialized cable for underwater divers
- The difference between different types of automotive cables and selection advice
- China manufacturer Communicate cable RVVP 4*0.3mm2 for power generation
- IEC62196-2 mode 3 16A single-phase electric vehicle charging process
- Automotive high-voltage cables with protection class IP67 characteristics
Product Details
Place of Origin: | Hebei, China | Brand Name: | YITENG | Model Number: | YJV22 YJLV22 YJV23 YJLV23 |
Insulation Material: | XLPE | Type: | Low Voltage | Application: | Industrial |
Conductor Material: | Aluminum | Jacket: | PVC |
Product Description
Copper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cableCopper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cableCopper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cableCopper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cableCopper/ Aluminium STA/ SWA Armoured Power Cable power cable 25mm 35mm 50mm 120mm 300mm copper armored cable
Power Cable 0.6-1KV XLPE Insulated SWA Steel Wire Armored Cable
1. SCOPE
This specification covers PVC or XLPE insulated, circular, twin, three or four
conductors armored cables, rated at 0.6/1 KV to international Electrotechnical
commission Publication IEC 60502-1 for use indoors, outdoors, in cable ducts, in
water and for direct burial underground, where severe mechanical stresses are
present. These cables have high dielectric strength, an excellent resistance to
deformations under high temperature and pressure, and high resistance to ageing,
abrasion, moisture, chemicals, acids and oils.
2. CONSTRUCTION
2.1 Conductor
Plain, annealed electrolytic copper or Aluminum conductors, solid, circular
stranded, or sectoral stranded, conforming to the applicable requirements of IEC
60228.
2.2 Insulation
PVC based thermoplastic or XLPE thermosetting material, conforming to the
applicable requirements of IEC 60502-1.
2.3 Assembly
Insulated conductors are laid up, filled where necessary with non-hygroscopic
material and covered with an extruded thickness of thermoplastic material.
2.4 Armor
Galvanized round wires, or flat strips, completely covering the assembly of cores
and a counter helix of galvanized steel tape on top; or two layers of steel tape,
complying to the applicable requirements of IEC 60502-1.
2.5 Sheath
PVC based thermoplastic material, conforming to the applicable requirements of
IEC 60502-1.
2.6 TESTS
Conforming to the applicable requirements of IEC 60502-1 either on Raw materials
or on finished products.
3. Types and Descriptions for Power Cable 0.6-1KV XLPE Insulated SWA Steel Wire Armored Cable:
Armored Cable Type | Low Voltage Armored Power Cable Specification | |
Copper Core | Aluminum Core | |
VV22 | VLV22 | Galvanized Steel Tape Armored Power Cable With PVC Insulation and PVC Sheath |
VV23 | VLV23 | Galvanized Steel Tape Armored Power Cable With PVC Insulation and PE Sheath |
VV32 | VLV32 | Fine Steel Wire Armored Power Cable With PVC Insulation and PVC Sheath |
VV33 | VLV33 | Fine Steel Wire Armored Power Cable With PVC Insulation and PE Sheath |
VV42 | VLV42 | Thick Steel Wire Armored Power Cable With PVC Insulation and PVC Sheath |
VV43 | VLV43 | Thick Steel Wire Armored Power Cable With PVC Insulation and PE Sheath |
YJV22 | YJLV22 | Galvanized Steel Tape Armored Power Cable With XLPE Insulation and PVC Sheath |
YJV23 | YJLV23 | Galvanized Steel Tape Armored Power Cable With XLPE Insulation and PE Sheath |
YJV32 | YJLV32 | Fine Steel Wire Armored Power Cable With XLPE Insulation and PVC Sheath |
YJV33 | YJLV33 | Fine Steel Wire Armored Power Cable With XLPE Insulation and PE Sheath |
YJV42 | YJLV42 | Thick Steel Wire Armored Power Cable With XLPE Insulation and PVC Sheath |
YJV43 | YJLV43 | Thick Steel Wire Armored Power Cable With XLPE Insulation and PE Sheath |
Welcome to our factory! Hope to get in touch with you!
Factory Name | Yiteng Cable Technology HebeiCo.,Ltd |
Location | Ningjin Town, Shijiazhuang, Hebei, China |
Establishes in | 1994, 20 years' experience of producing kinds of cables |
Export Office Location | Area1 Donghai Building, Shijiazhuang, Hebei, China |
Our Main Cables Products | Low Voltage Power Cable and Medium Voltage Power Cable with or without Armor(Armor Type:Steel Tape or Steel Wire) High Temperature Cable,Silicone Rubber Insulated Cable, Teflon Insulated Cable Mining Cable, Flexible Rubber Mining Cable, PVC and XLPE Aluminum Alloy Cable with/ without Armor and Interlock Shielded/ Screened Control Cable Computer Shielded Cable Flexible Rubber Cable Electrical Wires |
1. Any inquiries will be replied within 24 hours.
2. OEM/ODM available.
1) Printing your logo on the cable.
2) Printing your logo on the pull box, wooden drum according to your design
3) Any your idea on cable, packing box are available.
3. High quality, reasonable and competitive price, fast lead time.
4. Good after-Sale Service.
1) All products will have been strictly Quality Checked in house before packing.
2) All products will be well packed before shipping.
5. Faster delivery.
Sample order in stock, and 3-7 days for bulk production.
6. Payment
We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.
7. Package
Standard Export Wooden or Steel Drums or as per Customer's Requirement
8. ISO9001, ISO14001, CCC Certificates for Factory and Cable Products
