Despription:
This Hopper Spiral Conveyor Machine can convey sorts of material. Combined with the package-machine of our company, it can do material situation tracing. Also can be used separately. Complete machine made in stainless steel, except for the electrical machine, gearing, and the framework.
Characteristics:
l Vibrating screw feeding machine is composed of double motor, feeding motor, vibrating motor and each switch control.
l Hopper is adjustable and vibrational which make material to be flowing easily. It is good to material.
l Hopper is separate from twisting shaft. Structure is reasonable and easily loading and unloading.
l Characteristic dustproof, bearing won’t be polluted by the dust and powder.
l To cleanup scrapped materials conveniently and design the machine to be: Discharging the material reversally, storing materials at the bottom of hopper pipe, taking out the whole screw.
Technical Data:
Model |
JB-3 |
JB-5 |
JB-6 |
JB-8 |
JB-10 |
Capacity |
3m3/h |
5 m3/h |
6 m3/h |
8 m3/h |
12 m3/h |
Speed |
20-140 |
20-140 |
20-140 |
20-140 |
20-140 |
Inverter |
Select |
Select |
Select |
Select |
Select |
Pipe Diameter |
φ114 |
φ141 |
φ159 |
Φ168 |
Φ219 |
Motor |
0.77W |
1.57KW |
2.26KW |
3.06KW |
4.06KW |
Power |
1.52KW |
2.22KW |
3.02KW |
4.02KW |
5.57KW |
Weight |
130kg |
170kg |
200kg |
220kg |
270kg |
Hopper Volume |
200L |
200L |
200L |
200L |
200L |
Shrinkable film packaging and Wooden Package or Container
Our machine has 1 year quality guarantee period
24 hours hotline and Foreign maintenance department
We join China FIC API CPHI many exhibitions in China.
Our machine sell for Food industry, Chemical Industry, Pharmaceutical Industry.
1, What is the Screw Conveyor Feeder function ?
The screw conveyor feeder machine could conveyor dry granules or powders to mixer, crusher, packaging machine.
2, Does the screw conveyor feeder have feeding hopper?
Yes, it has 200L hopper for loading material, and if you want bigger more hopper, pls tell us.
3, What is the discharge height ?
Usually the standard height is 2000mm high.
4, What capacity it can make ?
We have 5 models, from 3-12 m3/h like you want.
5, What material does the screw conveyor feeder make ?
We could do stainless steel 304 or 316L made, and the screw is light polishing.
6, What about your country motor, elelctricity use ?
We use ABB/WEG motor, Schneider electricity brand.
Yes! They are populary in your market !
The fair show :
