Description
Cable type and number of pairs: cable UTP (unshielded twisted pair -- unshielded twisted pair) to the internal pads, 4 pairs (solid),
Category 5e.
Specifications
Conductor: bare copper wire O0.51 ± 0.01 mm, 24 AWG
Insulation: High density polyethylene, minimum thickness of 0.18 mm
Conductor diameter 0.9 ± 0.02 mm
4 twisted pairs are covered with PVC jacket (minimum thickness of the shell 0.4 mm)
The external cable diameter of 5.1 ± 0.2 mm
bending radius: 8xO during installation, 6xO with vertical
Cabling, 4xO the horizontal cabling
Standard packing: 18.5 x 37.5 x 36.5 cm (W x H x D) - 305 m
Weight without cable, weight: 9.7 kg
Cable Weight with packaging: 10.5 kg
Weight 1 km of cable: 31.8 kg
Operating temperature: -20 ° C - +75 ° C
Fire: CM
Standards: UL444/UL1581, TIA / EIA 568B.2
Electrical
Conductor resistance at 20 ° C 9.38 Om/100 m
DC Resistance Unbalance 5%
Capacitive unbalance pair to ground 330 pF/100m
Impedance 0.772-100 MHz 85-115 Ohm
Maximum working capacity of 5.6 nF / m
AFTER-SALE SERVICE
Our slogan is "Survive depends on quality,develop based on service."
Our promise, so long as product quality has question, upon test and find out if they are our fault, we can exchange or resupply to you for free with my company connection
