Home > Products > NETWORK CABLE > UTP LAN CABLE
UTP LAN CABLE
USD $0.30 - $0.30
/ Piece
500 Pieces(Min.Order)
- 500000 Piece / Pieces per Month
- SHENZHEN
- Credit Card
You May Like
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | OEM | Model Number: | CAT7 |
| Type: | Cat 7 | Number of Conductors: | 8 |
Product Description
Product Description
| Mode | Cat 7 lan cable | |||
| Conductor Size | 28AWG,26AWG,24AWG,23AWG,22AWG | |||
| Conductor Material | BC/CCA | |||
| No.of Conductor | 4P | |||
| Insulation Material | PE , HDPE | |||
| Jacket | PVC, ROHS PVC, LSZH PVC | |||
| Shield | Single conductive aluminum foil + Braid | |||
| Indoor/Outdoor | Single Jacket | |||
| Insulation Thickness | 0.2mm | |||
| Jacket Thickness | 0.92-0.95mm | |||
| Stretching Resistance | (max)250N | |||
| Impedance | 100±15Ω | |||
| DC Resistance Imbalance | 5.00% | |||
| Working Capacitance(Max.) | 5.6nF/100m | |||
| Max propagation delay skew | 30ns/100m | |||
| Rated Voltage | 60Vrms | |||
| Transmission Rate | 80% | |||
| Operating Temperature | -20 °C - +60 °C | |||
| PVC Jacket Color | Optional | |||
| Print Words On Cable | As Clients' Request | |||
