Home > Products > NETWORK CABLE > FLAT PATCH CORD UTP CAT5E
FLAT PATCH CORD UTP CAT5E
USD $2.00 - $2.00
/ Piece
500 Pieces(Min.Order)
- 50000 Piece / Pieces per Month
- shenzhen
You May Like
Product Details
Place of Origin: | Guangdong, China | Brand Name: | OEM | Model Number: | YTL012386 |
Type: | Cat 5e | Number of Conductors: | 8 |
Product Description
Product Description
Item No | 01 | 02 | |
Cable type | UTP CAT5E | FTP CAT5E | |
Conductor | Diameter(mm) | 0.505±0.005 | 0.515±0.005 |
Material | Bare Copper/CCA | Bare copper /CCA | |
Type | Solid | Solid | |
Dielectric(Insulation) | Diameter(mm) | 0.91±0.01 | 1.00±0.02 |
Material | PE | PE | |
colors | Pair 1 : Blue,White / Blue Pair 2 : Orange,White / Orange Pair 3 : Green,White / Green Pair 4 : Brown,White / Brown | ||
Shielding | Material | - | Aluminium+ foil +Tinned copper drain wire |
Coverage | - | 100% | |
Jacket(sheath) | Diameter(mm) | 5.1±0.2 | 5.6±0.2 |
Thickness(mm) | 0.55±0.05 | 0.55±0.05 | |
Material | Flame retardant PVC/PE | PE/PVC | |
colors | CUSTOMIZED | CUSTOMIZED | |
Number of Pairs | 4pairs | 4pairs | |
Length(m) | 305 | 305 | |
package | 305M/Roll in Box | 305M/Roll in Box | |
Dimensions | Box Size(mm) | 34x34x21 | 42x42x21 |
CBM/Box | 0.024 | 0.038 | |
Net Weight (kgs/box) | 9 | 12 | |
Gross Weight (kgs/box) | 10 | 13 | |
Electrical characteristics | |||
Attenuation | (100MHz dB/100m) | ≤22.0 | ≤22.0 |
NEXT | (100MHz dB/100m) | ≥35.3 | ≥35.3 |
ELFEXT | (100MHz dB/100m) | ≥23.8 | ≥23.8 |
RL | (100MHz dB/100m) | ≥20.11 | ≥20.11 |
Impedance (ohms ) | 100±15 | 100±15 | |
Operating Temperature Range(℃) | -20 to 75 | -20 to 70 |
