1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved

1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-1
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-2
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-3
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-4
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-5
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved thumbnail-6
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-1
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-2
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-3
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-4
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-5
1.2 Ton Full Electric Double-Pallet Stacker (CDD12) With CE Approved photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
Marshell
Contact Supplier Request Quote Chat Now
Shenzhen Marshell Green Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name Marshell
Model Number CDD12
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 1200KG
Max. Lifting Height 3000mm
Min. Lifting Height 80mm
Fork Length 685mm
Fork Width 685mm
Overall Dimensions 2550x790x2070mm
Certification CE
After-sales Service Provided Overseas third-party support available

1.2 ton Full Electric Double-Pallet Stacker (CDD12) with CE approved

Main configuration

1, maintenance-free ac drive system
2, electronic steering system
3, 24 v / 270 ah high-capacity lead-acid batteries
4, Curtis communication controller
5, import a two-speed hydraulic power unit
6, the side with quick replacement battery structure
7, a variety of specifications door frame to meet different customer needs

suitable mode

1, relatively flat cement or similar hard pavement
2, suitable for single pallet handling, stacking of the goods
3, suitable for high frequency and heavy load cargo handling, stacking
4, working time is about 5 hours



TIPS

 Does not apply to contain flammable and explosive gas or dust

1.2 ton Full Electric Double-Pallet Stacker (CDD12) with CE approved

Model

 CDD12
Load capacity/rated load kg 1200
Load center distance          C mm 600
Overall length               L1 mm 1463
Overall width               b1 mm 800
Overall height               h1 mm 2052
Wheelbase               Y mm 1240
Lowered fork height       h4 mm 85
Lift height           h5 mm 3000
Minimum ground clearance       h6 mm 30
Fork outside spacing       b2 mm 560
Fork inside spacing      b3 mm 240
Fork length           h7 mm 1150
Fork length          e mm 160
Front wheel tread             b4 mm 400
Max.lift speed unladen mm/s 160
laden mm/s 120
Max.travel speed unladen km/h 3.5
aden km/h 3.5
Minimum outside turning radius   Wa mm 1408
Max.gradability,laden % 3
Max.gradability,unladen % 5
Service weight(with battery) kg 620
Battery capacity Ah 80
Battery voltage V 24
(DC)Lift motor(DC) KW 2.2
(AC)Drive motor(AC) KW 0.75
Ast  Aisle width for lengthways 1000x1200 Pallets mm 2225
800x1200 Pallets mm 2150

1.2 ton Full Electric Double-Pallet Stacker (CDD12) with CE approved

1.2 ton Full Electric Double-Pallet Stacker (CDD12) with CE approved1.2 ton Full Electric Double-Pallet Stacker (CDD12) with CE approved
