CE Certified Fully Powered Electric Pallet Stacker (CDD16)
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
Marshell
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Washing Machine Cheap Mini Washing Machine (DQX5/5A)NegotiableMOQ: 1 Unit -
Cable Type Single-Brush Ground Cleaning Machine Floor Scrubber (DQX5/5A)NegotiableMOQ: 1 Unit
-
Auto Washing and Drying Scrubber, Cleaning Machine (DQX5/5A)NegotiableMOQ: 1 Unit
-
Smart Electric Hand Push Type Floor Scrubber Machine (DQX5/5A)NegotiableMOQ: 1 Unit
-
Hard Floor Cleaning Scrubber Machine (DQX5/5A)NegotiableMOQ: 1 Unit
Condition
New
Place of Origin
Shanghai, China
Brand Name
Marshell
Model Number
CDD16
Type
Powered Pallet Truck
Power Souce
AC Motor
Rated Loading Capacity
1600KG
Max. Lifting Height
3000mm
Min. Lifting Height
80mm
Fork Length
685mm
Fork Width
685mm
Overall Dimensions
2550x790x2070mm
Certification
CE
After-sales Service Provided
Overseas third-party support available
CE Certified Fully Powered Electric Pallet Stacker (CDD16)
Main configuration
1, maintenance-free ac drive system
2, electronic steering system
3, 24 v / 270 ah high-capacity lead-acid batteries
4, Curtis communication controller
5, import a two-speed hydraulic power unit
6, the side with quick replacement battery structure
7, a variety of specifications door frame to meet different customer needs
suitable mode
1, relatively flat cement or similar hard pavement
2, suitable for single pallet handling, stacking of the goods
3, suitable for high frequency and heavy load cargo handling, stacking
4, working time is about 5 hours
TIPS
Does not apply to contain flammable and explosive gas or dust
CE Certified Fully Powered Electric Pallet Stacker (CDD16)
| Model | CDD16 | |||
| Load capacity | Q(kg) | 1600 | ||
| Load centre distance | c(mm) | 600 | ||
| Overall length | I1/I2(mm) | 2550/2062 | ||
| Overall width | b1(mm) | 790 | ||
| Overall height | h6(mm) | 2070 | ||
| Fork height,lowered | h3(mm) | 85 | ||
| Max.lift height | h1(mm) | 3000 | ||
| Wheelbase | y(mm) | 1420 | ||
| Fork outside spacing | b2(mm) | 685 | ||
| Fork inside spacing | b4(mm) | 315 | ||
| Fork width | e(mm) | 185 | ||
| Front tread | b3(mm) | 500 | ||
| Max.lift speed | unladen | mm/s | 160 | |
| laden | mm/s | 120 | ||
| Max. travel speed | unladen | km/h | 6 | |
| laden | km/h | 6 | ||
| Turning radius | W1(mm) | 1600 | ||
| Max. gradability,laden | % | 5 | ||
| Max. gradability,unladen | % | 8 | ||
| Service weight(with battery) | kg | 1300 | ||
| Battery capacity | Ah | 270 | ||
| Battery voltage | V | 24 | ||
| Aisle width for lengthways | Pallets 1000x1200 | Ast(mm) | 2500 | |
| Pallets 800x1200 | Ast(mm) | 2400 | ||
CE Certified Fully Powered Electric Pallet Stacker (CDD16)
