Help CenterServo Motor Driven Full Auto Garbage Bag Making & Folding Machine
Related Products
-
Servo Motor Driven Full Auto Garbage Bag Making & Folding Machine for T-Shirt Style & Flat StyleNegotiableMOQ: 1 Set -
Servo Motor Driven Full Automatic Perforating & Floded T Shirt Bag On Roll Making Machine With Automatic Rewinding ModuleNegotiableMOQ: 1 Set
-
Servo Motor Driven Perforating Bag on Roll Making MachineNegotiableMOQ: 1 Set
-
Servo Motor Driven Full Automatic Perforating Bag On Roll Making Machine With Automatic Rewinding ModuleNegotiableMOQ: 1 Set
-
Servo Motor Driven Full Automatic Perforating Bag On Roll Making MachineNegotiableMOQ: 1 Set
Specifications
In China,First bag folding machine made by SINGSIANG. 3,4 or 5 fold available, 1 min fold 90 pcs bags, LABOR SAVING! EASY PACKAGIn China,SINGSIANG made out the First bag folding machine, SHGF series floding machine can fold bag for 3,4 or 5 times, in 1 minute, theSHGF can fold 90 pcs bags, Tremendous Labor Saving! Super Easy for Package and use!!
Special Features | ||
|
Servo Motor Driven, Efficient mechanical structure |
Automatically stop when running out of film |
|
Fully Automatic, Large control panel Screen , Easy to read, User Friendly |
Automatically stop when film feeding blocks or bags jam |
|
Efficient output, less man power required |
Automatically stop when The temperature not reaching setting. |
|
Digital setup, accurate registration, less waste |
Automatically stop when the bags become super-imposed or overlapped |
|
Special formulate for Sealing Blade, make Pleasant Cutting and Sealing, with high firmness |
|
|
Cutting Blade is imprted from Taiwan,which is very lasting, and easy for adjustment |
|
Optional Accessories | |||
|
Free Tension Sealing Blade (for Thick Bags) |
|
Air Punching Unit |
SPECIFICATION | ||||||||||
MODEL |
MAX. WIDTH |
MAX. LENGTH |
CONVERTING THICKNESS |
ACCURACY LENGTH(m/m) |
SPEED (PCS/MIN) |
SERVO MOTOR |
HEATER |
POWER REQUIRED |
DIAMENSION |
MACHINE WEIGHT |
SHGF-30 |
750 mm |
1200 mm |
0.01 - 0.1 mm |
± 1 |
10 - 120 |
1.5 KW |
2.0 KW |
5.0 KW |
550*142*144 |
1700 KG |
SHGF-36 |
890 mm |
1200 mm |
0.012-0.15 mm |
± 1 |
10 - 110 |
2.0 KW |
2.2 KW |
5.5 KW |
6420*157*165 |
1800 KG |
SHGF-42 |
1050 mm |
1200 mm |
0.012-0.15 mm |
± 1 |
10 - 95 |
3.0 KW |
2.5 KW |
6.0 KW |
640*173*165 |
2000 KG |
SHGF-50 |
1250 mm |
1200 mm |
0.012-0.15 mm |
± 2 |
10 - 80 |
4.4 KW |
3.0 KW |
6.5KW |
640*193*165 |
2100 KG |
SHGF-60 |
1500 mm |
1200 mm |
0.035-0.15 mm |
± 2 |
10 - 70 |
4.4 KW |
3.80 KW |
7.0 KW |
640*219*165 |
2300 KG |
