New arrival 3G/4G WiFi Industrial Router with RS232/485/422 for data transmission
HJ8100 series 3G/4G WiFi router is an industrial router used for IoT data transmission, and it provides wireless data transmission to terminals over 3G/4G, WiFi or Ethernet, 433/315.
HJ8100 series adopt high-performance technical-grade processor and wireless data module combined with embedded Linux OS to ensure stability and safety of data transmission. The hardware is equipped with two RS232/485/422 ports, one WAN port and one WiFi access point. It can simultaneously connect with serial port devices, Ethernet devices, WiFi devices and 240~930MHz RF devices to realize transparent transmission and routing function.
This product has been widely used in IoT industry, such as smart grid, ITS(Intelligent Transportation System), industrial automation, intelligent building, environmental protection, smart healthcare, agriculture, water affairs, smart home, mobile POS terminal, financial, petroleum and petrochemical, monitoring, etc.
Specifications
|
General Parameters |
Processor |
Embedded MIPS24KEc |
Working frequency |
580Mhz |
|
Memory |
128MBytes DDR2 |
|
Flash |
32MBytes |
|
WIFI |
802.11n 2.4 GHz 150M |
|
Power Input |
DC 9~28V |
|
Power consumption |
1A/12V |
|
Working temperature |
-20~80℃ |
|
Storage temperature |
-30 ~85℃ |
|
Operating humidity |
5 - 95%RH |
|
Dimension |
110 x 105 x 28.5mm |
|
Network |
Speed |
10/100M Auto |
Electromagnetic isolation |
2KV |
|
Network Protocol |
IP/TCP/UDP/DHCP/DHCPD/DNS/HTTP/SNMP |
|
MAX TCP Connectors |
4096 |
|
SDK Soft |
PHP5.5 |
|
Setting Mode |
Software / Webserver |
|
WiFi |
Frequency |
2.4G |
Interface |
SMA RF Antenna |
|
Transmission power |
+16.5 DB (802.11n) |
|
Sensitivity |
-75DB (802.11n) |
|
Encryption |
WPA/WPA2 TKIP/AES |
|
Transmission Distance |
200 meters |
|
Work Mode |
Station/AP |
|
3G/4G |
Port |
1 |
3G Frequency |
UMTS/HSPA+; 850/1900MHz;UMTS/HSPA+900/2100MHz; UMTS/HSPA+; 800(850)/2100MHz; GSM/GPRS/EDGE 850/900/1800/1900MHz; GSM/GPRS/EDGE 850/900/1800/1900MHz; GSM/GPRS/EDGE 850/900/1800/1900MHz |
|
4G Frequency |
GSM 850MHz; EGSM 900MHz; DCS1800MHz; PCS1900MHz; WCDMA 850MHz; WCDMA 900MHz; WCDMA 1900MHz; WCDMA 2100MHz; 1880-1920MHz; 2010-2025MHz; LTE-FDD B1; LTE-FDD B2; LTE-FDD B3; LTE-FDD B4; LTE-FDD B5; LTE-FDD B7; LTE-FDD B8; LTE-FDD B13; LTE-FDD B17; LTE-FDD B20; LTE TDD B38; LTE TDD B39; LTE TDD B40; LTE TDD B41 |
|
RS232/485/422 |
COM Port |
2 |
Baud rate |
300~230400BPS |
|
Data bit |
5/6/7/8 Bits |
|
Stop Bit |
1/2 Bits |
|
Check |
None/Odd/Event |
|
Buffer Size |
4MBytes |
|
RS232 Interface |
DB9 Female Head and Male Pin |
|
RS485/422 Interface |
Two Line (A,B) |
Application
