Help CenterAutomatic Aluminum Cover Capping Machine
Related Products
-
Automatic Linear Capping MachineNegotiableMOQ: 1 Set -
Automatic Rotary Capping MachineNegotiableMOQ: 1 Set
-
Gusset Pouch Filling MachineUS$ 6,000 - 80,000MOQ: 1 Set
-
2015 Unique Sealing Technology Automatic Sachet Packaging Machine Quality ChoiceUS$ 6,000 - 40,000MOQ: 1 Set
-
CE Approval Back Sealing Automatic Liquid Paste Packaging MachineNegotiableMOQ: 1 Set
Specifications
- Applicable for aluminium cap capping closing/sealing- Suitable for small bottle
- Low damage ratio
• Special design for small bottle like antibiotics bottle capping with aluminum caps or aluminum-plastic caps.
• Adapting outward turning flexible rolling head , with low damage ratio.
• Frequency-conversion to control speed, reliable performance with low noise
• Automatic counting
• Equipped with high-quality Stainless Steel 304 integrated structure, reasonable product design.
• Assurance of key components’ quality by selecting of International reputable brands
Issue |
Application Description |
Application |
Special design for small bottle like antibiotics bottle capping with aluminum caps or aluminum-plastic caps |
Type of caps |
Aluminum, Aluminum-Plastic caps |
No |
Issue |
Description of Material / Brand |
1 |
Frame & Body |
Made of Stainless Steel 304 |
2 |
Motor |
Teco, Delta |
3 |
Programmable Logic Controller |
Delta, Siemens, AB |
4 |
Electric Components |
Schneider |
5 |
Protection & Relay |
Schneider |
Catalogue |
1A-AC-120 |
Control Method |
Automatic |
Number of Closing Head |
2 |
Container Moving Method |
Rotary |
Capping Speed |
120 Bottles/Min- for capacity less than 10ml 80 Bottles/Min- for capacity 25-50 ml 60 Bottles/Min- for capacity 50-100ml |
Compress Air Required |
Not Applicable |
Air Consumption |
Not Applicable |
Power Requirement |
AC 380V 50/60HZ |
Electricity Consumption |
1.1Kw |
Vacuum Requirement |
No |
Cap Pre-Heating |
No |
Cap Pre-Plugging |
No |
Container Auto-Sorting |
Yes |
With Shied |
No |
Explosive-Proof |
Not Applicable |
Approximate Weight ( Net) |
200kg |
Dimension ( ‘mm ) |
1520*900*1400mm |
Following documents are available, but not limited, to be provided upon the stage of purchasing
No |
Document |
Code |
Description |
1 |
Products Selection Guide |
SG |
To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement |
2 |
Products Profile |
PP |
To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features |
3 |
Installation Instruction |
IN |
To explain the step of installation of the equipment, and include commissioning instruction as well |
4 |
User Manual |
UM |
To cover the content of Operation & Maintenance and Trouble Shooting |
Customization Philosophy
The product demonstrating may not perfectly meet your requirements, our philosophy is to customize your real need, To minimizing idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:
- Container to be capped, Dimension, Material.
- Type of Cap, number, position and dimension of Cap
- Capacity requirement
- Automation requirement
- Protection requirement
- Other specific requirement
Selection Guide
Selection Guides are available for circulation, contact us to get products selection and customization support.
Statement
- The pictures demonstrating in this profile represent products of range, and subject to the newest or customized design
- Due to the huge number of documentation updating, the data indicated in this profile may not be updated timely, Please contact with our customer service for newest version.
- The features or functions appear in this profile subject to the additional description of quotation
