Automatic Rotary Capping Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Guangzhou
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Beverage, Chemical, Commodity, Food
Driven Type	Electric	Automatic Grade	Automatic
Voltage	AC 380V 50/60HZ	Power	2.2KW
Packaging Type	Bottles	Packaging Material	Glass, Paper, Plastic
Place of Origin	Guangdong, China	Brand Name	GS
Model Number	C-813-1A-A-001	Dimension(LWH)	350012002000mm
Weight	1200kg	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

- Clamp caps automatically and vertically
- Auto display & count
- Magnetic moment capping head, no scrape

Product Description

• Commonly suitable for cap-screwing of container with different diameter of caps.

• Instead of traditional cap-hanging structure, this kind of machine adopts cap-screwing head to grabbing caps automatically and vertically, thus effectively avoiding inclined caps and ensuring high capping precision.

• Frequency-conversion to control speed, reliable performance with low noise

• Automatic counting capping machine

• Applying magnetic moment capping head, easy to adjust the tightness, no scrapes

• Equipped with high-quality Stainless Steel 304 integrated structure, reasonable product design.

• Assurance of key components’ quality by selecting of International reputable brands

Application

Issue	Application Description
Application	Commonly suitable for cap-screwing of container with different diameter of caps.
Type of caps	Aluminum, Plastic caps and so on
Diameter of cap	15-80mm
Diameter/Width of Container	<= 150mm

Construction

No	Issue	Description of Material / Brand
1	Frame & Body	Made of Stainless Steel 304
2	Motor	Teco, Delta
3	Programmable Logic Controller	Delta, Siemens, AB
4	Electric Components	Schneider
5	Protection & Relay	Schneider

Typical Products

Catalogue	1A-AC-6H	1A-AC-8H
Special apply for	Commonly Cap-Screwing	Commonly Cap-Screwing
Control Method	Automatic	Automatic
Number of Screwing Head	6	8
Container Moving Method	Rotary	Rotary
Height of Container	<=300mm	<=300mm
Diameter of Caps	40-80mm	15-40mm
Capping Speed	5000-10000 Bottles/Hr	5000-1000 Bottles/Hr
Conveying Width	<=150mm		<=150mm
Diameter/Width of Container	<=150mm	<=150mm
Compress Air Required ^**1)	0.4-0.6Mpa	0.4-0.6Mpa
Air Consumption	20M³/Hour	20M³/Hour
Power Requirement	AC 380V 50/60HZ	AC 380V 50/60HZ
Electricity Consumption	2.2Kw	2.2Kw
Vacuum Requirement	No	No
Cap Pre-Heating	No	No
Cap Pre-Plugging	No	No
Container Auto-Sorting	Yes	Yes
With Shied	No	Yes
Explosive-Proof	Not Applicable	Not Applicable
Approximate Weight ( Net)	1200kg	1500 kg
Dimension ( ‘mm )	350012002000mm	360012002000mm

Documentation

Following documents are available, but not limited, to be provided upon the stage of purchasing

No	Document	Code	Description
1	Products Selection Guide	SG	To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement
2	Products Profile	PP	To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features
3	Installation Instruction	IN	To explain the step of installation of the equipment, and include commissioning instruction as well
4	User Manual	UM	To cover the content of Operation & Maintenance and Trouble Shooting

Service

Customization

Customization Philosophy

The product demonstrating may not perfectly meet your requirements, our philosophy is to customize your real need, To minimizing idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:

Container to be capped, Dimension, Material.
Type of Cap, number, position and dimension of Cap
Capacity requirement
Automation requirement
Protection requirement
Other specific requirement

Selection Guide

Selection Guides are available for circulation, contact us to get products selection and customization support.

The pictures demonstrating in this profile represent products of range, and subject to the newest or customized design
