Made in China Self-unload Small Garbage Truck, Garbage Truck Dimensions

FOB Price

US$ 6,000 - 9,000 / Set

1 Set(Min. Order)

Port any port in china
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Drive Wheel	4x2
Type	Recycling	Transmission Type	Manual
Emission Standard	Euro 3	Volume	1000 - 3000L
Fuel Type	Diesel	Engine Capacity	1809
Size	485020902600	Gross Vehicle Weight	4495
Place of Origin	Hubei, China	Brand Name	jiangte
Model Number	JDF5051ZZZ	Certification	3c ISO BV
After-sales Service Provided	Overseas service center available

Product Description

Specifications

made in China self-unload small garbage truck, garbage truck dimensions
1.High Quality Chassis, competitive prices
2. ISO ,3C

made in China self-unload small garbage truck, garbage truck dimensions

Our Services

1.We are professional manufacturers to do the special vehicles . We are supply all brands of special truck , north benz(beiben) , Faw , Foton , Shaanxi ,Sinotruck , Jac , Jmc , Isuzu ,Dongfeng all available .

2.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4

3.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles .

Product advantage:

1. Factory export department directly sale ,realiable quality

2.Export experience more than 12 years

3.Cheap / competitive price, high quality ,you get more than your paid

4.With CCC, ISO , BV approved

5. The heart of the service, rational design

Product Description

Product parameters:

Product model	garbage truck for sale
Product parameters	Total mass(Kg)	4495
	Rated weight(Kg)	1800
	Curb weight(Kg)	2300
	Overall dimension(mm)	485020902600
	Carriage dimensions (mm)	/

Chassis parameters	Chassis model	BJ1041SJ35D6
	Fuel type	Diesel
	Emission standard	Euro 4

Engine parameters	Engine model	4D18E
	Manufacturer	QUANCHAI
	Displacement(ml)	1809
	Power(Kw)	47

Main Parameters	Rated person of Cab	2
	Number of axles	2
	Wheelbase(mm)	2800
	Axle load(Kg)	1530/2980
	Tires No.	6
	Tyre size	6.00-14
	Max. speed(Km/h)	95
	Approach angle /Departure angle (°)	19/16
	Front overhang /Rear overhang (mm)	990/1315
	Front track/Rear track(mm)	1385/1225

Main Product :

We are professional manufacturer for many kind of special trucks .

WORKSHOP AND CERTIFICATION :
